PROGRAM TIMER
19
PW-6242B
3) Set up the file structure inside SD Card as above. If you modify or delete folder name arbitrarily, it will
n
ot be operated normally.
4) Under the status that it is connected with PC via USB cable, the function and system will not be
operated. When using this function,
remove the cable connected to PC and then proceed the function.
5) It is faster in file uploading/downloading speed by mounting SD Card directly onto PC rather than
uploading/downloading the file by connecting with PC after mounting SD Card onto the equipment.
When uploading/downloading the large capacity of file, mount SD Card directly onto PC and then
proceed.
6) Boot the product completely and then, connect with PC.
7) When connecting with PC via USB cable during playing the scheduled broadcasting and the sound
source, the equipment may show the malfunction. Do not connect with PC via USB cable during
playing the scheduled broadcasting and the sound source.
8) TLC type of SD CARD is recommended and other type of SD CARD may not be compatible.
16. MP3 FILE COPY USING USB TERMINAL
It is a function to copy MP3 file using USB memory connecting terminal.
1) When connecting USB memory with USB memory connecting terminal at front side, it is automatically
recognized. At this point, USB INSERT is displayed on display window.
2) The files copied from USB memory are saved within MP3 COPY folder and they can be
uploaded/downloaded from/into PC or deleted directly.
※ When connecting USB memory with the equipment during playing the scheduled broadcasting and the
sound source, the equipment may show the malfunction. Do not connect USB memory with the equipment
during playing the scheduled broadcasting and the sound source.
17. COMMUNICATION SPEED SETTING
When connecting PV-6232A or PC, you must set up communication speed for each product. If it is not
matched, you cannot control PV-6232A.
1) When pushing UP button longer, the setting starts.
2) Whenever pushing UP button, the communication speed value varies. If pushing ENTER button after
changing into the desired communication speed, the setting value is saved. If pushing CANCEL button
during the setting, it is cancelled.
※ When connecting with PC, set up communication speed according to the communication speed set by
PC program.
uP
MODEL Baud Rate
PV-6232A 19200bps
PC 9600bps/19200bps
