Inter-m PW-642 - PC and RS-232 C Connectivity

PROGRAM TIMER
15
PW-642
PC and RS-232C Connection
PC and RS-232C Connection
P
W-64
2
PW-642(Female
)
PC(Female)
PC
Pin No.
1
2
3
4
5
6
7
8
9
PW-642Definition
NC
RxD
TxD
NC
GND
NC
NC
NC
NC
# 2 RxD
# 3 TxD
# 5 GND
# 2RxD
# 3TxD
# 5GND
D-SUB 9Cable(Twisted RS-232C Cable
)
PC
6
7
8
9
1
2
3
4
5
6
7
8
9
1
2
3
4
5
