Inter-m PW-642 - Technical Specifications

8x8 AUDIO MATRIX
17
PW-642
PROGRAM TIMER
PW-642
Input Channel(Balanced) 5CH
Output Channel(Balanced) 4CH
Output Level Maximum 1V
AC Power Output 1 Maximum 500W
AC Power Output2 Maximum 30W
Data Preservation Time 7 days and more
No. 1 2 seconds
No. 2 3 seconds
No. 3 3 seconds
No. 4 5 seconds
No. 5 5 seconds
No. 6 7 seconds
Melody Time No. 7 7 seconds
(15 settings total - 247 seconds) No. 8 10 seconds
No. 9 10 seconds
No. 10 15 seconds
No. 11 20 seconds
No. 12 30 seconds
No. 13 30 seconds
No. 14 40 seconds
No. 15 60 seconds
Operation Temperature -10°C ~ +40°C
Power Source
100–120VAC or 220–240VAC; 50/60Hz
(Supplied AC mains transformer depends on country requirements)
Power Consumption 10W
Weight (SET) 5.7kg / 12.6lb
Dimensions (SET) 482(W)x88(H)x380(D)mm / 19(W)x3.5(H)x15(D)in
* Specifications and design are subject to change without notice.
