22
NORMAL LIMIT
TUNER SECTION–FM SYS-2120 SYS-2240 SYS-2120 SYS-2240
Tuning Range 87.5MHz~108MHz 87.5MHz~108MHz
Calibration Error 16kHz less than 30kHz
Usable Sensitivity (at Pre Amp Out)
14dB less than 20dB
98MHz, 75kHz Mod, S/N 30dB: los
Signal to Noise Ratio (at Pre Amp Out)
67dB 50dB
98MHz, 75kHz MOD, 1mV
Distortion (at Pre Amp Out)
1% less than 1.5%
98MHz, 1mV, 75kHz MOD
Tuned LED Sensitivity 15dB 15dB±7dB
Frequency Response (+2dB/–3dB)
18Hz~3kHz 200Hz~1.7kHz
98MHz, 1mV, 75kHz MOD. 75µsec
Output (at OPT Out 100V tap)
100V over than 90V
98MHz, 1mV, 722.5k MOD. 1kHz)
TUNER SECTION–AM
Tuning Range 522kHz~1611Hz 522kHz~1611kHz
Calibration Error 0.5kHz less than 3kHz
Usable Sensitivity (30% MOD., 999kHz)
30dB less than 40dB
(Direct Input: loss –6dB)
Signal to Noise Ratio (999kHz, 1mV, 30% Modulation) 53dB 40dB
Distortion (999kHz, 1mV, 30% MOD. 400Hz) 1% 2%
Frequency Response (999kHz, 1mV,
280Hz~2.1kHz 300Hz~1.2kHz
30% MOD. 400Hz, +2dB/–3dB)
Output (999kHz, 1mV, 30% MOD. 1kHz) 100V over than 90V
CD SECTION
Frequency Response 100Hz (4 Track) ±0.5dB ±3dB
1kHz (2 Track) ±0.5dB ±3dB
10kHz (5 Track) ±0.5dB ±3dB
Signal to Noise Ratio (Weighted A) 1kHz 70dB 65dB
Distortion 0dB (20k LPF) 0.30% less than 1%
Output Voltage/Impedance 1kHz (–10dB) 100V over than 90V
Access Time: Track to Next Track 1.0 sec 2.0 sec
Disc to Disc 9.0 sec 12.0 sec
Disc Defects: Block Dot 900uM 800uM
Interrupt 800uM 700uM
Fingerprint All
De-Emphasis 5kHz –20dB –20dB±3dB
16kHz –20dB –20dB±3dB
GENERAL
Power Source AC 100V–240V, 50/60Hz
Power Consumption SYSTEM 2120: 300W
SYSTEM 2240: 470W
Weight SYSTEM 2120: 24kg
SYSTEM 2240: 25kg
Dimensions 420(W)
266(H) 310(D)mm
*Specifications and design subject to change without notice for improvements.
23
ELECTRICAL PARTS LIST
CN707 4428595013 LW5267/LWB0640/2.5MM-13P 13P
AN706 4428596604 LOCK WAFER LW-1143-04P
AN705 4428596606 LOCK WAFER LW-1143-06P 6P
CN705
IL1 4448997410 AC INLET 6100.4315 250T SCURTE AC INLET
RY701 5528009810 RELAY VKP-31H42 31H42
Q709 2008206105-T TR PNP KAT 1268 KTA 1268
Q701 Q704 2008206106-T TR PNP KTA2400G KEC KTA 2400G
Q719
Q708 2008606104-T TR NPN KTC 3198Y KTC 3198Y
Q702-Q703 2008606117-T TR NPN KTC3400G KEC KTC 3400G
Q718
R757 3039100572-F RES MO 10 2W J N 10 2W
R730-R731 3039100575-T RES MO 10 2W JR 10 2W
R729 3039221572-F RES MO 220 2W J N 220 2W
R756 3039479572-F RES MO 4.7 2W J N 4.7 2W
R792-R793 3039821572-F RES MO 820 2W J N 820 2W
SVR701 3248333120-T RES SEMI 330 N6L25T1N 330B
C713 3409210071-T CAP AF RSG 10UF 50V 5 P 10/50
C709 C742 3409210141-T CAP AF RSG 100UF 25V 6 P 100/25
C764-C765 3409233071-T CAP AF RSG 33UF 50V 6 P 33/50
C702 3409247041-T CAP AF RSG 47UF 25V 5 P 47/25
C740 3409810141-T CAP AF NP 100UF 25V 100/25 NP
C714-C715 3419547091-T CAP E SG 47UF/100V 10 P 47/100
C701 3509471231-A CAP CE B 470PF 50V K AXIAL 470P
C721-C722 3529104531-A CAP CE F 100000PF 50V Z 100000P
C725-C726
C729-C730
C752, C754
C756, C759
C762-C763
C704 3529150311-A CAP CE SL 15PF 50V J AXIAL 15P
C773-C774
C707-C708 3609104120-T CAP MA 0.1UF 100V J 0.1/100(M)
C705-C706 3609472120-T CAP MA 0.0047UF 100V J 0.0047/100(M)
F1,F2,F3,F4 4458999110 FUSE CLIP 5*20
F1,F2,F3,F4 5508112737 FUSE 51S 20MM 2A/250V K/U/C/J
5508412734 FUSE TS 20MM 2A 250V U/C/S B,C,D,E
AN306 4353983802 CON ASS’Y 11P 90MM CON 11P
AN305 4428536329 CON ASS’Y 4P 100MM CON 4P
LD301-318 2308232222-T SLR 34URF 25 LED
LCD301 2338170394 LCD KXN29150DAN CD KEC KXN2915DAN
S301 4628985710 TACT (5MM) SKHV10906A (KBW89) REPEAT
S302 4628985710 TACT (5MM) SKHV10906A (KBW89) CLEAR
S303 4628985710 TACT (5MM) SKHV10906A (KBW89) MEMORY
S304 4628985710 TACT (5MM) SKHV10906A (KBW89) DISPLAY
S305 4628985710 TACT (5MM) SKHV10906A (KBW89) RESET
S306 4628985710 TACT (5MM) SKHV10906A (KBW89) STOP
S307 4628985710 TACT (5MM) SKHV10906A (KBW89) PLAY
S308 4628985710 TACT (5MM) SKHV10906A (KBW89) S-FF
S309 4628985710 TACT (5MM) SKHV10906A (KBW89) S-REW
S310 4628985710 TACT (5MM) SKHV10906A (KBW89) FF
S311 4628985710 TACT (5MM) SKHV10906A (KBW89) REW
S312 4628985710 TACT (5MM) SKHV10906A (KBW89) DISC
S313 4628985710 TACT (5MM) SKHV10906A (KBW89) MODE
S314 4628985710 TACT (5MM) SKHV10906A (KBW89) RANDOM
AN307 4353981003 CON ASS’Y 4P 100MM CON 4P
S315 4628985710 TACT (5MM) SKHV10906A (KBW89) DISC1
S316 4628985710 TACT (5MM) SKHV10906A (KBW89) DISC2
S317 4628985710 TACT (5MM) SKHV10906A (KBW89) DISC3
AN303 4355743201 CON ASS’Y 8P 80MM 8P
AN304 4353983601 CON ASS’Y 4P 80MM 4P
AN305 4428536329 WAFER FMN-BTRK-29P/IMM,JST WAFER 29P
AN306 4353983802 CON ASS’Y 11P 90MM
CON ASS’Y 11P
AN307 4353981003 CON ASS’Y 4P 100MM CON ASS
’
Y 4P
AN308 4353982614 CON ASS’Y 8P 300MM CON ASS
’
Y 8P
AN309 4353982105 CON ASS’Y 2P 120MM
CON SHIELD ASS’Y
AN310 4353982913 CON ASS’Y 3P 270MM
CON SHIELD ASS’Y
C304 3409210141-T CAP AF RSG 100UF 25V 6 P 100/25
C305 3409210141-T CAP AF RSG 100UF 25V 6 P 100/25
Ref No. Part No. ValueDescription
CD DISPLAY B’D (4003317410)
CD EJECT B’D (4003317420)
CD B’D (4003317400)
Ref No. Part No. ValueDescription
Q721 2008005999 TR PNP 2SA 1546 NEC 2SA 1546
Q722 2008405999 TR NPN 2SC4001 NEC 2SC 4001
Q720 2028107115 TR PNP 2SA968Y 2SA 968Y
Q715-Q717 2028117994 TR PNP 2SA 1492 W/ACC 2SA 1492
Q726 2028117994 TR PNP 2SA 1492 W/ACC SYS2240
Q724 2028407118 TR NPN 2SC 2238Y 2SC 2238Y
Q723 2028407990 TR NPN 2SC 3298A(Y),KTC4370A(Y) 2SC 3298A
Q712-Q714 2028427998 TR 2SC 3856 W/ACC 2SC 3856
Q725 2028427998 TR 2SC 3856 W/ACC SYS2240
BD700 2058100103 DIODE KBPC-2504(SB256)LUG TYPE KBPC 2504
D709-D710 2058100110 DIODE RL207 PYUNG CHANG RL207
BD701- 2058100983 DIODE BRIDGEPBL302P/KBL403/404 PBL 302P
BD703
D711-D713 2058100996 DIODE RECTIFIER LT1N4006(4007) 1N 4006
D716-D717
D701-D708 2058304100 DIODE IN4148M 1N 4148
IC703 2118011405 IC KIA 7806 API KEC 7806
IC701 2118011605 IC KIA 7809 API KEC 7809
IC702 2118011905 IC KIA 7815 API KEC 7815
IC705 2118012005 IC KIA 7818 API KEC 7818
IC704 2118050410 IC TA7317P TOSHIBA TA 7317P
IC706 2128611100 IC KA7918 COMMON 7918
PO701 2438007993 POSISTOR PTH 9M04 BE 222TS 2F POSIST
TH701 2438209021 THERMISTOR YSG-501K 500
L701 2648099940 COIL INDUCTOR 1.2UM 1.2uH
R720-R721 3009101973 RES CF 100 1/5W J N 100
R701 3009102973 RES CF 1K 1/5W J N 1K
R712-R713
R718 -R719
R769-R770 3009104973 RES CF 100K 1/5W J N 100K
R703 3009123973 RES CF 12K 1/5W J N 12K
R794 3009153973 RES CF 15K 1/5W J N 15K
R763 3009154973 RES CF 150K 1/5W J N 150K
R706-R707 3009181973 RES CF 180 1/5W J N 180
R724 3009221973 RES CF 220 1/5W J N 220
R759 R762 3009223973 RES CF 22K 1/5W J N 22K
R766-R767
R708-R711 3009332973 RES CF 3.3K 1/5W J N 3.3K
R768 3009334973 RES CF 330K 1/5W J N 330K
R714-R717 3009470973 RES CF 47 1/5W J N 47
R723 3009471973 RES CF 470 1/5W J N 470
R758 3009561973 RES CF 560 1/5W J N 560
R702 3009563973 RES CF 56K 1/5W J N 56K
R722 3009681973 RES CF 680 1/5W J N 680
R704-R705 3009683973 RES CF 68K 1/5W J N 68K
R764-R765 3009822973 RES CF 8.2K 1/5W J N 8.2K
R726-R727 3009823973 RES CF 82K 1/5W J N 82K
R750-R755 3049478783 RES CE 0.47 5W J T HAN NAE 0.47 5W
R773-R774
R760-R761 3059100772 RES CE 10 5W JN 10 5W
R790-R791 3059470782 RES CE 47 5W J N 47 5W
R725 R728 3079101275 RES ERD-2FCVG 101T 1/4W R FR 100
R732-R733 3079332275 RES ERD-2FCVG 332T 1/4W R FR 3.3K
R776-R783 3089101275 RES NFR 100 1/4W J R PHILKO FR 100
R744-R749 3089479275 RES NFR 4.7 1/4W J R PHILKO FR 4.7
R771-R772
C723-C724 3408210261 CAP RSG 1000UF 35V SNAP 16 P 1000/35
C727-C728, 3408247141 CAP RSA 470UF 25V SNAP 13 P 470/25
C755
C760-C761
C719-C720, 3419233261 CAP E RSG 3300UF 35V 3300/35
C751 C753
C758
C771-C772 3419510300 CAP HM 10000UF/80V 35P*60 10000/80
C711-C712 3609334130 CAP MA 0.33UF 150V 0.33/150(M)
AN702 4353983416 CON ASS'Y 3P 360MM 3P
P5-P6 4355789306 CON ASS'Y 1P ORG 250T
P4 4355789403 CON ASS'Y 1P BLK 250T
P7 4355789207 CON ASS'Y RED 250T
CN702 4355923603 WAFER 7.62MM B 5 5P
CN602 4428595002 LW5267/LWB0640/2.5MM-02P 2P
CN603 4428595003 LW5267/LWB0640/2.5MM-03P 3P
AN703 4428595005 LW5267/LWB0640/2.5MM-05P 5P
AN704 4428595008 LW5267/LWB0640/2.5MM-08P 8P
AMP B’D (4005410000)
