4 5

Ref. Part N o. Description Value Ref. Part N o. Description Value

D216-218 R124 R126 R134

D221-222 R166 R188-189

D301-305 D312 R203 R240 R242

D6 D8 D30 S22501048001 DIODE MURS160T3 MOTOROLA MUR160T3 R251 R282 R303

D9 D26-29 S22501448001

DIODE,SW,1A,600V,MURS120TS,DO-214AA,TA

MURS120T3 R305

D306 S22620620010 DIODE,ZN,350MW,BM,6.2V,BZX84C6 6.2V R115 R128 R190 S30135905230 RES,TF,5.9K,1/10W,1%,2012 5.9K 1%

D14 S22621100010 DIODE,ZN,350MW,BM,10V,BZX84C10 10V R215 R244 R308

R97-98 R163 S30101017231 RES,TF,100,1/10W,5%,2012 100 R343 S30139095331 RES,TF,9.09K,1/8W,1%,2012 9.09K 1%

R193 R220-221 R11 R18 S30141005230 RES,TF,100,1/10W,1%,2012 100 1%

R270 R279 R109 R230 R313 S30143835331 RES,TF,383,1/8W,1%,2012 383 1%

R108 R204-205 S30101027340 RES,TF,1K,1/8W,5%,3216 1K R316

R229 R320 R324 R101 R117 R219 S30144755230 RES,TF,475,1/10W,1%,2012 475 1%

R326 R236

R106 R206 R228 S30101047231 RES,TF,100K,1/10W,5%,2012 100K R17 R33 R114 S30145365331 RES,TF,536,1/8W,1%,2012 536 1%

R335 S30101237231 RES,TF,12K,1/10W,5%,2012 12K R214

R102-105 R112 S30101527231 RES,TF,1.5K,1/10W,5%,2012 1.5K R325 S30146345440 RES TF 634F 1/4W 3216 634 1%

R118-119 R213 R38 S30151005230 RES,TF,10,1/10W,1%,2012 10 1%

R224-227 R34 R51 S30153925441 RES,TF,39.2,1/4W,1%,3216 39.2 1%

R232-233 R311-312

R338-339 R314-315

R120 R235 S30101537231 RES,TF,15K,1/10W,5%,2012 15K R131 R192 R247 S30154755230 RES,TF,47.5,1/10W,1%,2012 47.5 1%

R19-20 R43 R45 S30101547340 RES,TF,150K,1/8W,5%,3216 150K R310

R47 R123 R125 R9-10 R35 S30301005440 RES,MF,10,1/4W,1%,3216,TA 10 1%

R184-185 R239 R16 S30337875330 RES MF 7.87K F 2012 7.87K

R241 R302 R304 R137 R167 R253 S30342745330 RES,MF,274,1/8W,1%,2012,TA 274 1%

R141 R170 R257 S30102017231 RES,TF,200,1/10W,5%,2012 200 R283

R287 C107 C203 S35101004330 CAP,CE,MONO,COG,10PF,50V,J,2012 10P

R122 R238 R333 S30102027231 RES,TF,2K,1/10W,5%,2012 2K C101 C109 C201 S35101014331 CAP,CE,MONO,COG,100PF,50V,J,2012 100P

R99 R222 R318 S30102037231 RES,TF,20K,1/10W,5%,2012 20K C209

R321 R327-328 C29 C45 C309 S35101024344 CAP,CE,MONO,X7R,1000PF,50V,5% 1000pF

R332 C311 C313

R52 S30102737231 RES,TF,27K,1/10W,5%,2012 27K C19-23 C26 C38 S35101044344 CAP,CE,MONO,X7R,0.1UF,50V,K,3216 0.1U

R155-156 S30107507231 RES,TF,75,1/10W,5%,2012 75 C44 C104 C117

R272-273

C122 C127 C207

R111 R207-209 S30107527230 RES TF 7.5K J 1/10W 2012 7.5K

C217 C222 C227

R217 C307

R36-37 R136 S30111045440 RES,TF,100K,1/4W,1%,3216 100K C33-35 C110 S35102725434 CAP,CE,MONO,X7R,2700PF,100V 2700P

R139 R164 R195

C115 C124 C210

R250 R255 R280 C215 C224

R285 R337

C112 C126 C128

S35104704331 CAP,CE,MONO,COG,47PF,50V,J,2012 47P

R30 R100 R127 S30113925331 RES,TF,392K,1/8W,1%,2012 392K 1%

C211 C226 C228

R187 R223 R243 C25 C27-28 S35104714344 CAP,CE,MONO,COG,470PF,50V,J,3216 470P

R307 R336 R345

C36-37 C48 C105

R23-24 R27-28 S30114875441 RES,TF,487K,1/4W,1%,3216 487K 1%

C119 C205 C219

R14-15 R31-32 S30121005230 RES,TF,10K,1/10W,1%,2012 10K 1% C118 C218 S35106815331 CAP,CE,MONO,COG,680PF,50V,J,2012 680P

R42 R46

R22 R44 R92-93 S30121275230 RES,TF,12.7K,1/10W,1%,2012 12.7K 1%

R95 R107 R116 ZD401-402 2058502024 DIODE,ZN,500MW,BM,2.4V,DO-35,T 2.4BM

R121 R130 R154 LD401 LD407 2300030100 LED,RND 3.1MM,RED,DIF,1U,ST2.5 LTL-1CHE

R201-202

LD402-406 LD408

2300032100 LED,RND 3.1MM,GRN,DIF,1U,ST2.5 LTL-1CHG

R211-212 VR401-402 3228066600

VR,ROT,VER,1U,L15,10K,B,RV16ADO-41-15F

10KB

R234 R237 R246 AN402 4355429120

CON ASS'Y,RB,16P,IDC2.54,DIP2.54,480MM

ASS'Y-16P

R271 R322-323 LIM1-8 8545993340 LED LIMITER LED LIMITER

R344 C402 C404 3409210023-T CAP,E,SM,SE,85C,10UF,50V,M 10/50

R12 S30121505230 RES TF 15K F 1/10W 2012 15K 1% Q401-402 S20510405004

TR,SG,PNP,200MA,40V,2N3906S,SOT-23,TA

2N3906S

R41 S30122005230 RES,TF,20K,1/10W,1%,2012 20K 1% Q404-405

R26 S30122495331 RES,TF,24.9K,1/8W,1%,2012 24.9K 1% Q407-408

R183 R194 S30123325441 RES,TF,33.2K,1/4W,1%,3216 33.2K 1% Q403 Q406 S20560448002

TR,SG,NPN,200MA,40V,MMBT3904,SOT-23,TA

2N3904

R300-301 D401-404 S22400500001 DIODE,SW,0.2A,200V,BAS21,SOT-23 BAS21

R25 R29 R96 S30123925331 RES,TF,39.2K,1/8W,1%,2012 39.2K 1% R402 R405 S30101027340 RES,TF,1K,1/8W,5%,3216 1K

R135 R140 R165 R401 R403-404 S30134755331 RES,TF,4.75K,1/8W,1%,2012 4.75K 1%

R169 R218 R252 R406

R256 R281 R286 C401 C403 S35104714344 CAP,CE,MONO,COG,470PF,50V,J,3216 470P

R319 R346

R186 R306 S30124755331 RES,TF,47.5K,1/8W,1%,2012 47.5K 1%

R39 S30131005230 RES,TF,1K,1/10W,1%,2012 1K 1% C601-602 3630104500 CAP,FILM,M-POLYESTR,0.1UF,250V 0.1/250(M)

R334 S30131745331 RES,TF,1.74K,1/8W,1%,2012 1.74K 1% JK603-604 4430001200 JACK,SPEAKON,1U,4P,ST,FC60112 4P

R48-49 R110 S30132215331 RES,TF,2.21K,1/8W,1%,2012 2.21K 1%

R138 R168 R191

R210 R231 R254 AN501 4355429008 CON ASS'Y,RB,14P,IDC2.54,DIP2.54,170MM ASS'Y-14P

R284 R309 R317 JK402 JK404 4438192910 JACK,PHONE,1U,5P,ST PHONE

R329-331 JK401 JK 403 4438193810 JACK,XLR(F),1U,3P,ST XLR(F)

R94 R129 R245 S30133015230 RES,TF,3.01K,1/10W,1%,2012 3.01K 1% SW501 SW503 4618499310 SW SLIDE SS84017-0403-5.3T-FN SS84017

R864 SW506

R13 R21 R40 R91 S30134755331 RES,TF,4.75K,1/8W,1%,2012 4.75K 1% SW504-505 4628991710 SW,PUSH,VER,DPDT,NS,1U,L12.5 SPEC122SC011

VR B'D (4000006610 )

O UTPUT B'D (40000 06620)

INPUT B'D (400 0006900)

Ref. Part N o. Description Value

BK501 6505955520 PCB BKT MX-400 BRACKET

C521-522 3409210071-T CAP,E,SM,SG,85C,10UF,50V,M 10/50

C503 C508 C511 3409847041-T CAP,E,NP,NP,85C,47UF,25V,M 47/25 NP

C516

C505 C513 3609683120-T CAP,FILM,POLYESTR,0.068UF,100V 0.068/100

C507 C515 3639224188-T CAP,FILM,M-POLYESTR,0.22UF,63V 0.22/63(M)

C506 C514 3639473188-T CAP,FILM,M-POLYESTR,0.047UF,63V 0.047/63(M)

U501-504 S21101087701 IC,OP AMP,NE5532A,SOP8 NE5532A

D501-504 S22400500001 DIODE,SW,0.2A,200V,BAS21,SOT-23 BAS21

R531-532 S30100007230 RES,TF,0,1/10W,5%(J),2012 0

R505 R518 S30101037231 RES,TF,10K,1/10W,5%,2012 10K

R506 R519 S30101047231 RES,TF,100K,1/10W,5%,2012 100K

R512 R525 S30102037231 RES,TF,20K,1/10W,5%,2012 20K

R527-530 S30107507231 RES,TF,75,1/10W,5%,2012 75

R507 R513 R520 S30107527230 RES TF 7.5K J 1/10W 2012 7.5K

R526

R508 R521 S30121375230 RES,TF,13.7K,1/10W,1%,2012 13.7K 1%

R511 R524 S30124755331 RES,TF,47.5K,1/8W,1%,2012 47.5K 1%

R509 R522 S30133655230 RES,TF,3.65K,1/10W,1%,2012 3.65K 1%

R510 R523 S30134755331 RES,TF,4.75K,1/8W,1%,2012 4.75K 1%

R501-504 S30135605230 RES,TF,5.6K,1/10W,1%,2012 5.6K 1%

R514-517

C501-502 S35101014331 CAP,CE,MONO,COG,100PF,50V,J,2012 100P

C509-510

C523-524 S35101045331 CAP,CE,MONO,X7R,0.1UF,50V,Z,2012 0.1U

C504 C512 S35102204339 CAP,CE,MONO,COG,22PF,50V,J,2012 22P

C517-520 S35104714330 CAP,CE,MONO,COG,470PF,50V,J,2012 470P

AC CORD 4308997410 AC POWER CORD (16A/250V) 230VAC

AC CORD 4308997610 AC POWER CORD (15A/125V) 120VAC

AC INLET 4448597210 AC INLET 3P 2.0T 16A/20A 4793

CONNECTOR 4355429504 CON ASS'Y,DS,1P,R5.3,250T08,110MM

CONNECTOR 4355429510 CON ASS'Y,DS,1P,R5.3,250T08,210MM

CONNECTOR 4355810803 CON ASS'Y,DS,1P,250T08,ST4.2,100MM

FAN 1,2 7308997510 DC FAN(3110KL-05W-B70-F04)

SW 4648099810

SW,POWER,18A,250V,AJ1-B0-44-618-5C2-D

230VAC

SW 4648099920 SW POWER AJ1-B0-44-635-5C2-C 120VAC

ASS'Y
