ELECTRICAL PARTS LIST (V-4000)ELECTRICAL PARTS LIST (V-4000)
Ref. Part N o. Description Va lue Ref. Part N o. Description Value
AN11,AN12 4355428921 CON ASS'Y,DS,2P,P2.6,P2.6,510MM ASS'Y
AN1 4355429300 CON ASS'Y,DS,1P,P2.6,P2.6,40MM ASS'Y
E4-5 1508400501 JUMP WIRE(0.5/52M/M) JUMPER AN5 4355429303 CON ASS'Y,DS,1P,P2.6,P2.6,100MM ASS'Y(120VAC)
Q305 2028106960 TR,PW,PNP,3A,100V,TIP32C TIP32C AN9,AN10 4355716121 CON ASS'Y,DS,2P,P2.6,P2.6,510MM ASS'Y
Q115-119 2028107118 TR,PW,PNP,15A,230V,2SA1943,TO-3P(L) 2SA1943 AN2 4355791712 CON ASS'Y,DS,1P,P2.6,P2.6,250MM ASS'Y
Q219-223 J19 4355795704 CON ASS'Y,DS,1P,250T08,P2.6,110MM ASS'Y
Q114 Q218 2028107995 TR,PW,PNP,8A,250V,MJE15033,TO-220 MJE15033 J20 4355833204 CON ASS'Y,DS,1P,250T08,P2.6,110MM ASS'Y
Q125 229 2028110941 TR,PW,PNP,1A,230V,2SA1837 2SA1837 CN1 4428592513 CON WAFER,BOX(M),14P,2/ST PC1635-14P
Q130-134 2028407122 TR,PW,NPN,15A,230V,2SC5200,TO-3P(L) 2SC5200 CN2 4428592516 CON WAFER,BOX(M),16P,2/ST PC1635-16P
Q234-238 CN301-302 4428595003 CON WAFER,BOX(M),3P,ST LW5267-03P
Q129 Q233 2028407995 TR,PW,NPN,8A,250V,MJE15032,TO-220 MJE15032 CN3-4 4465998210 TERMINAL(250)PCB TAB 250T
Q120 Q224 2028410884 TR,PW,NPN,1A,230V,2SC4793,TO-220IS 2SC4793 RL1 5528009851 RELAY AZ2151-1C-24DE ZETTLER DC 24V
Q1-2 2028900101 TR,IGBT,JF N,27A,600V,IRG4PC50 IRG4PC50W HS301 7505299310 HEAT SINK(30MM) REG TR Heat sink
2048247900 TR,PW,MF N,60A,60V,NTP60N06G,TO-220 NTP60N06 LIM101 LIM201 8545993380 LED LIMITER LED LIMITER
Q241 Q124 Q228 2008005998-T TR,SG,PNP,200MA,40V,2N3906 2N3906
D114 D119 D215
2058100106 DIODE,RE,3A,400V,1N5404,DO-201A 1N5404 Q121 Q225 2008405998-T TR,SW,NPN,200MA,40V,2N3904 2N3904
D219 R113 R216 3022165455-T RES,MF,16.5K,1W,1%,RA A,TA 16.5K 1W 1%
BD1 2058199100 DIODE,BR,50A,600V,RBV5006,RBV25 RBV5006 R3-4 3029303575-T RES,MF,30K,2W,5%,RA A,TA 30K 2W
D20-23 2058300995 DIODE,RE,15A,400V,MUR1540,TO-2 MUR 1540 R158 R160-162 3039150575-T RES,MF,15,2W,5%,RA R,TA 15 2W
D113 D120 D214 2058300996 DIODE,RE,15A,200V,MUR1520,TO-220AC MUR 1520 R274 R276-278
D220 R353 3039151575-T RES,MF,150,2W,5%,RA R,TA 150 2W
D18-19 D24-25 2058499700
DIODE,SW,30A,400V,DSEP30-04A,TO-247AD
DSEP30-04A R348 3039159575-T RES,MF,1.5,2W,5%,RA R,TA 1.5 2W
D2-3 2058499800
DIODE,SW,4A,400V,MUR440,DO-201AD
MUR440 R6-8 R157 R159 3039569575-T RES,MF,5.6,2W,5%,RA R,TA 5.6 2W
D105 D206 2058502039 DIODE,ZN,500MW,BM,3.9V,DO-35,T 3.9BM R200 R275
D313 2058502240 DIODE,ZN,500MW,BM,24V,DO-35,TA 24BM VR101 VR201 3248550120-T RES SEMI FT-63 TP(500) 500
D307-310 2058510150 DIODE,ZN,1W,BM,15V,DO-41,TA 15BM C24 3409210039-T CAP,EC,SM,WB,10UF,16V,M,5X11,T 100/16
D311 2058512150 DIODE,ZN,1W,BM,12V,DO-41,TA 12V 1W C30 C43 C111 3409210062-T CAP,E,SM,SS,85C,10UF,35V,M 10/35
D106 D207 2058512190 DIODE,ZN,1W,BM,10V,DO-41,TA 10V 1W C212 C312
U101 U201 2118013377 IC,OP AMP,NE5532P,DIP8 5532N C40-42 C69 C71 3409210140-T CAP,EC,SM,WB,100UF,25V,M 100/25
U2 2118031800 IC,PWM CONT,SG3525AN,DIP16 SG3525AN C73
U1 2128220089 IC,DRIVER,IR2110,DIP14P,IR IR2110
C108 C113 C208
3409210141-T CAP,E,SM,SG,85C,100UF,25V,M 100/25
U5 2128660000 IC,PWM SW,TOP210,DIP08P TOP210 C213 C316-318
PC1-2 2408000980 PHOTO COUPLER,1U,CNY17F-1,ON S CNY17F-1 C321
TH1 2438200960 THERMIST,NTC,20A,10OHM,85C,HJ NTC-10
C103 C206 C310
3409210971-T CAP,E,SM,SG,85C,1UF,50V,M 1/50
TH101 TH201 2438200970 KCL103F414FL,NTC,10K KCL103F
C114 C123 C214
3409222033-T CAP,E,SM,SE,85C,22UF,16V,M 22/16
L101 L201 2648099800 COIL,AIR,2.2UH 2.2 uH C223
L3-8 2648609800 COIL,FER,RADIAL,6UH 6uH C314 3409247071-T CAP,E,SM,SG,85C,47UF,50V,M 47/50
L9 2648699510 COIL,FER,TOROID,1.9UH,20A 1.9UH C46 C301-306 3409247147-T CAP,E,SM,SD,85C,470UF,25V,M 470/25
L1-2 2648699520 COIL,FER,TOROID,2.2MH,20A 2mH C32 3409710070-T CAP,E,NP,NP,85C,10UF,50V,M 10/50 NP
T2 2828053700 TRANS,PW,SMPS,Q-4300 TRANS
C102 C202 C308
3409847041-T CAP,E,NP,NP,85C,47UF,25V,M 47/25 NP
T1 2828053900 TRANS,PW,SMPS,EE,Q-3300/4300 TRANS C106 C204 3529150210-T CAP,CE,TEMP,NPO,15PF,50V,J,RA 15P
R1-2 3027503660 RES,MF,750K,1/2W,5%,AX M 750K 1/2W C120 C220 3609223120-T CAP,FILM,POLYESTR,0.022UF,100V 0.022/100(M)
R50 R142 R171 3029150572 RES,MF,15,2W,5%,AX M 15 2W C15 3609332120-T CAP,FILM,POLYESTR,0.0033UF,100V 0.0033/100(M)
R258 R288 TP101 TP201 4225000810-T TERMINAL,PIN,TEST,1P,TA TP
R153 R182 R269 3029159572 RES,MF,1.5,2W,5%,AX M 1.5 2W Q123 Q227 S20110402001 TR,SG,PNP,500MA,300V,KST92,SOT KST92
R299 Q122 Q226 S20160402009 TR,SG,NPN,500MA,300V,KST42MTF, KST42MTF
R143-152 3029478572 RES,MF,0.47,2W,5%,AX M 0.47 2W Q3-4 Q7 Q101 S20510405004
TR,SG,PNP,200MA,40V,2N3906S,SOT-23,TA
2N3906S
R172-181
Q104 Q106 Q109
R259-268 Q111-112 Q128
R289-298 Q136 Q202-205
R341-342 3032701960 RES,MO,2.7K,3W,5%,AX P 2.7K 3W
Q208 Q210 Q213
R340 3039331673 RES,MO,330,3W,5%,AX N 330 3W Q215-216 Q232
R354-355 3039471674 RES,MO,470,3W,5%,AX P 470 3W Q240 Q301-302
R5 3039560673 RES,MO,56,3W,5%,AX N 56 3W Q5-6 Q8 S20560448002
TR,SG,NPN,200MA,40V,MMBT3904,SOT-23,TA
2N3904
R349-350 3039681674 RES,MO,680,3W,5%,AX P 680 3W Q102-103 Q105
R351-352 3039821674 RES,MO,820,3W,5%,AX N 820 3W Q107-108 Q113
R132-133 3039822674 RES,MO,8.2K,3W,5%,AX N 8.2K 3W Q126-127 Q135
R248-249 Q201 Q206-207
R347 Q209 Q211-212
C49-53 C64-68 3409247189 CAP,E,SM,WB,470UF,63V,M,16X20 470/63 Q217 Q230-231
C54-63 3409247199 CAP,EC,SM,WB,470UF,100V,M,18X40 470/100 Q239 Q303-304
C7-10 3419027205 CAP,EC,LA,LS,2700UF,200V,M,35X70 2700/200 U4 S21101142601 IC,OP AMP,LM339,SOP14 LM339MX
C2-3 C13 C39 3549222091 CAP,CE,AC,Y2/X1,2200PF,250VAC 2200P250 U102 S21101167701 IC,OP AMP,NJM13600M,DMP16 NJM13600M
C74 U301 S21102084801 IC,COMP,LM393,SOP08 LM393D
C70 C72 C116 3630104500 CAP,FILM,M-POLYESTR,0.1UF,250V 0.1/250(M) U103-104 S21102087701 IC,COMP,LM311,DMP8 LM311D
C121 C125 C216
U202-203
C221 C225 C315
U3 S21283142601 IC,TIMER,LM556CM,SOP14 LM556CM
C320 D1 D4-5 D7 S22400500001 DIODE,SW,0.2A,200V,BAS21,SOT-23 BAS21
C16 C31 C319 3639104600 CAP,FILM,M-POLYESTR,0.1UF,400V,K 0.1/400(M) D10-13 D15-17
C6 3649104251 CAP,FILM,AC,X2,0.1UF,250VAC,K 0.1/250 D101-104
C47 3659101179 CAP,FILM,MICA,100PF,500V,J 100P500 D107-112
C17-18 3659331179 CAP,FILM,MICA,330PF,63V,J 330P500 D115-118 D121
C1 C4 3669105208 CAP,FILM,M-POLYPRPN,1UF,275V 1/275(M) D201-205
C5 3669474208 CAP,FILM,M-POLYPRPN,0.47UF,275V 0.47/275(M) D208-213
C14 3670474600 CAP,FILM,M-POLYPRPN,0.47UF,400V,J 0.47/400(M) D216-218
Ref. Part N o. Description Va lue Ref. Part N o. Description Va lue
D221-222 R282
D301-305 D312 R13 R21 R40 R91 S30134755331 RES,TF,4.75K,1/8W,1%,2012 4.75K 1%
D6 D8 D30 S22501048001 DIODE MURS160T3 MOTOROLA MUR160T3 R124 R126
D9 D26-29 S22501448001
DIODE,SW,1A,600V,MURS120TS,DO-214AA,TA
MURS120T3 R188-189 R203
D306 S22620620010 DIODE,ZN,350MW,BM,6.2V,BZX84C6 6.2V R240 R242 R303
D14 S22621100010 DIODE,ZN,350MW,BM,10V,BZX84C10 10V R305
R97-98 R163 S30101017231 RES,TF,100,1/10W,5%,2012 100 R115 R128 R190 S30135905230 RES,TF,5.9K,1/10W,1%,2012 5.9K 1%
R193 R220-221 R215 R244 R308
R270 R279 R343 S30139095331 RES,TF,9.09K,1/8W,1%,2012 9.09K 1%
R108 R204-205 S30101027340 RES,TF,1K,1/8W,5%,3216 1K R11 R18 S30141005230 RES,TF,100,1/10W,1%,2012 100 1%
R229 R320 R324 R109 R230 R313 S30143835331 RES,TF,383,1/8W,1%,2012 383 1%
R326 R316
R106 R206 R228 S30101047231 RES,TF,100K,1/10W,5%,2012 100K R101 R117 R219 S30144755230 RES,TF,475,1/10W,1%,2012 475 1%
R335 S30101237231 RES,TF,12K,1/10W,5%,2012 12K R236
R102-105 R112 S30101527231 RES,TF,1.5K,1/10W,5%,2012 1.5K R17 R33 R114 S30145365331 RES,TF,536,1/8W,1%,2012 536 1%
R118-119 R213 R214
R224-227 R325 S30146345440 RES TF 634F 1/4W 3216 634 1%
R232-233 R38 S30151005230 RES,TF,10,1/10W,1%,2012 10 1%
R338-339 R34 R51 S30153925441 RES,TF,39.2,1/4W,1%,3216 39.2 1%
R120 R235 S30101537231 RES,TF,15K,1/10W,5%,2012 15K R311-312
R19-20 R43 R45 S30101547340 RES,TF,150K,1/8W,5%,3216 150K R314-315
R47 R123 R125 R131 R192 R247 S30154755230 RES,TF,47.5,1/10W,1%,2012 47.5 1%
R136 R164 R310
R184-185 R239 R9-10 R35 S30301005440 RES,MF,10,1/4W,1%,3216,TA 10 1%
R241 R250 R280 R16 S30337875330 RES MF 7.87K F 2012 7.87K
R302 R304 R137 R167 R253 S30342745330 RES,MF,274,1/8W,1%,2012,TA 274 1%
R141 R170 R257 S30102017231 RES,TF,200,1/10W,5%,2012 200 R283
R287 C107 C203 S35101004330 CAP,CE,MONO,COG,10PF,50V,J,2012 10P
R122 R238 R333 S30102027231 RES,TF,2K,1/10W,5%,2012 2K
C101 C109 C201
S35101014331 CAP,CE,MONO,COG,100PF,50V,J,2012 100P
R99 R222 R318 S30102037231 RES,TF,20K,1/10W,5%,2012 20K C209
R321 R327-328 C29 C45 C309 S35101024344 CAP,CE,MONO,X7R,1000PF,50V,5% 1000pF
R332 C311 C313
R155-156 S30107507231 RES,TF,75,1/10W,5%,2012 75 C19-23 C26 C38 S35101044344 CAP,CE,MONO,X7R,0.1UF,50V,K,3216 0.1U
R272-273 C44 C104 C117
R111 R207-209 S30107527230 RES TF 7.5K J 1/10W 2012 7.5K
C122 C127 C207
R217
C217 C222 C227
R36-37 R139 S30111045440 RES,TF,100K,1/4W,1%,3216 100K 1% C307
R195 R255 R285 C33-35 C110 S35102725434 CAP,CE,MONO,X7R,2700PF,100V 2700P
R337
C115 C124 C210
R30 R100 R127 S30113925331 RES,TF,392K,1/8W,1%,2012 392K 1% C215 C224
R187 R223 R243
C112 C126 C128
S35104704331 CAP,CE,MONO,COG,47PF,50V,J,2012 47P
R307 R336 R345
C211 C226 C228
R23-24 R27-28 S30114875441 RES,TF,487K,1/4W,1%,3216 487K 1% C25 C27-28 S35104714344 CAP,CE,MONO,COG,470PF,50V,J,3216 470P
R14-15 R31-32 S30121005230 RES,TF,10K,1/10W,1%,2012 10K 1%
C36-37 C48 C105
R42 R46
C119 C205 C219
R22 R44 R92-93 S30121275230 RES,TF,12.7K,1/10W,1%,2012 12.7K 1% C118 C218 S35106815331 CAP,CE,MONO,COG,680PF,50V,J,2012 680P
R95 R107 R116
R121 R130 R140
R154 R169 ZD401-402 2058502024 DIODE,ZN,500MW,BM,2.4V,DO-35,T 2.4BM
R201-202 LD401 LD407 2300030100 LED,RND 3.1MM,RED,DIF,1U,ST2.5 LTL-1CHE
R211-212
2300032100 LED,RND 3.1MM,GRN,DIF,1U,ST2.5 LTL-1CHG
R234 R237 R246 VR401-402 3228066600
VR,ROT,VER,1U,L15,10K,B,RV16ADO-41-15F
10KB
R256 R271 R286 AN402 4355429120
CON ASS'Y,RB,16P,IDC2.54,DIP2.54,480MM
ASS'Y-16P
R322-323 R344 LIM1-8 8545993340 LED LIMITER LED LIMITER
R12 S30121505230 RES TF 15K F 1/10W 2012 15K 1% C402 C404 3409210023-T CAP,E,SM,SE,85C,10UF,50V,M 10/50
R41 R52 S30122005230 RES,TF,20K,1/10W,1%,2012 20K 1% Q401-402 S20510405004
TR,SG,PNP,200MA,40V,2N3906S,SOT-23,TA
2N3906S
R26 S30122495331 RES,TF,24.9K,1/8W,1%,2012 24.9K 1% Q404-405
R183 R194 S30123325441 RES,TF,33.2K,1/4W,1%,3216 33.2K 1% Q407-408
R300-301 Q403 Q406 S20560448002
TR,SG,NPN,200MA,40V,MMBT3904,SOT-23,TA
2N3904
R25 R29 R96 S30123925331 RES,TF,39.2K,1/8W,1%,2012 39.2K 1% D401-404 S22400500001 DIODE,SW,0.2A,200V,BAS21,SOT-23 BAS21
R135 R165 R218 R402 R405 S30101027340 RES,TF,1K,1/8W,5%,3216 1K
R252 R281 R319 R401 R403-404 S30134755331 RES,TF,4.75K,1/8W,1%,2012 4.75K 1%
R346 R406
R186 R306 S30124755331 RES,TF,47.5K,1/8W,1%,2012 47.5K 1% C401 C403 S35104714344 CAP,CE,MONO,COG,470PF,50V,J,3216 470P
R39 S30131005230 RES,TF,1K,1/10W,1%,2012 1K 1%
R138 R168 R254 S30131625331 RES,TF,1.62K,1/8W,1%,2012 1.62K 1%
R284 C601-602 3630104500 CAP,FILM,M-POLYESTR,0.1UF,250V 0.1/250(M)
R334 S30131745331 RES,TF,1.74K,1/8W,1%,2012 1.74K 1% JK603-604 4430001200 JACK,SPEAKON,1U,4P,ST,FC60112 4P
R48-49 R110 S30132215331 RES,TF,2.21K,1/8W,1%,2012 2.21K 1%
R191 R210 R231
R309 R317 AN501 4355429008
CON ASS'Y,RB,14P,IDC2.54,DIP2.54,170MM
ASS'Y-14P
R329-331 JK402 JK404 4438192910 JACK,PHONE,1U,5P,ST PHONE
R94 R129 R245 S30133015230 RES,TF,3.01K,1/10W,1%,2012 3.01K 1% JK401 JK 403 4438193810 JACK,XLR(F),1U,3P,ST XLR(F)
R864 SW501 SW503 4618499310 SW SLIDE SS84017-0403-5.3T-FN SS84017
R134 R166 R251 S30134325230 RES,TF,4.32K,1/10W,1%,2012 4.32K 1% SW506
O UTPUT B'D (40000 06620)
