Motherboard mounting

Dust filter cleaning

Pull out the dust filter

Power supply mounting

Insert power supply Attach to the case

HDD mounting

Mounting 3,5" at the bottom

Pull out HDD tray

3,5" clip

2,5" Screws

5

Motherboard mounting on the tray
