Interacoustics Affinity2.0 - Page 58

D-0004578-R – 2022/05 Page 54
Affinity2.0/Equinox2.0 - Instructions for Use - US
Sp 1, Sp 2, Sp 3, Sp 4
70Hz-20kHz ±3dB
Left, Right
Up to 7.0Vrms by 10Ω load
70Hz-20kHz ±3dB
Ins. Left, Ins. Right
Bone
Ins. Mask.
HF/HLS
Insitu L, Insitu R
Monitor, Ass. Mon.
Max.3.5Vrms. by 8 Ω load
70Hz-20kHz ±3dB
Sp. 1-4 Power Out
DC
Voltage: 5VDC
Current: 0.5A
TB Loop
Up to 100mA/meter
70Hz-20kHz ±3dB
FF Loop
Batt. Sim.
Voltage: 1.1 – 1.6VDC
Impedance range: 0 – 25 Ω.
Batt. Sim. - Internal TB
(Affinity2.0
only)
Data connections
USB/PC
USB B socket for connection to PC
(Compatible with USB 1.1 and later)
USB
USB A socket for connection of other USB
devices
(Internal USB 1.1 hub)
Keys.
Serial Peripheral Interface Bus (SPI
interface)
Check the Service Manual for more
inf ormation.
Internal test box:
Built in test box holds telecoil drive as well as special dual speaker set f or
checking directional microphone f unction.
Dimensions (LxWxH)
Aff inity2.0: 42 x 38 x 14 cm / 16.5 x 15 x 5.5 inches
Weight
Aff inity2.0: 5.5 kg / 12.1 lbs.
Power supply
100-240 V~, 50-60Hz
Power consumption:
195VA
Operation environment
Temperature: 15-35°
Re. Humidity: 30-90% Non-condensing
Ambient pressure range: 98kPa o 104kPa
Transport and storage
Transport temperature: -20-50°C
Storage temperature: 0-50°C
Re. Humidity: 10-95% Non-condensing
