Chapter 5: Menu reference
Advisor Advanced ATSx500A(-IP) Installation and Programming Manual 223
6.2.n.8 Log limit
If the Log limit option is set to Enable, only 3 pairs of activating (opening) and
restoring (or closing) events coming from a single output are recorded in the log
during one set/unset cycle.
6.2.n.9 Delete output
Use the Delete output screen to remove an output from the system. To remove
the output, select OK and press Enter again. The output is deleted.
6.3 Triggers
0>Add trigger
1 Trigger 1
The Triggers menu allows you to configure system triggers.
Trigger settings
6.3.0 Add trigger
Access the menu to add a trigger. If the trigger is created successfully, the
following message appears:
The new trigger is given the default name “Trigger N” and placed on the end of
the trigger list. You can now start editing the details for the new trigger.
6.3.n Select trigger
Select a trigger to program.
6.3.n.1 Trigger name
Every trigger can be programmed with a name to identify it.
Use the Trigger name screen to enter or change the trigger name. The trigger
name can contain up to 16 characters.
