Chapter 5: Menu reference
232 Advisor Advanced ATSx500A(-IP) Installation and Programming Manual
8 System option menu
1>Timer menu
2 Engineer opt
Use the System menu to program the global system options including timers.
8.1 Timer menu
1>Time&date
2 Siren options
Use the Timer menu to program all system wide timers in this section.
Notes
• Timers are accurate to ±1 of the value entered. So a timer set for 20 seconds,
ends somewhere between 19 and 21 seconds. Consequently, avoid using
values of 1 second or 1 minute.
• If a timer is set to 0, that timer is not used.
8.1.1 Time and date
The Time and date menu allows you to set the system time and date, as well as
set up daylight saving time.
The following options are available.
• 1 Time zone. The system time zone.
• 2 Date. Date format is DD-MM-YYYY.
• 3 Time. Time format is 24 hours.
• 4 DST start mth. The DST start month.
• 5 DST start wk. The DST start week. The available options are: 1st week, 2nd
week, 3rd week, 4th week, last week.
• 6 DST end mth. See above.
• 7 DST end wk. See above.
• 8 Set correction. Allows configuring time correction if necessary.
- 8.1 Time/7days. This submenu allows setting the time correction that is
performed each 7 days of panel work.
Maximum value is 5 min 40 s. Positive value means the clock is set forward,
negative — backward.
