Interlogix ATS3500A-IP-MM Installation And Programming Manual

Chapter 2: Installation
Advisor Advanced ATSx500A(-IP) Installation and Programming Manual 25
Zone state
EOL
Connection
details [1]
Measure [2]
Short
Masking
Normal
Alarm
Fault
Open
Single NC
(Item 1)
No EOL
R (kΩ)
—
—
<1
>1
—
—
U (V)
—
—
<3.5
>3.5
—
—
Note: Values for other EOL are equal to Dual, except all ranges but normal are
alarm ranges.
Single NO
(Item 2)
No EOL
R (kΩ)
—
—
>44.70
<44.70
—
—
U (V)
—
—
>11.14
<11.14
—
—
Note: Values for other EOL are equal to Dual, except all ranges but normal are
alarm ranges.
Dual
10K
(Item 4)
R (kΩ)
<3.33
3.33–
6.67
6.67–
13.33
13.33–
26.67
—
>26.67
RA=10 kΩ, RT=5 kΩ,
RF=5 kΩ
U (V)
<5.70
5.70–
8.10
8.10–
10.20
10.20–
11.70
—
>11.70
4K7
(Item 3)
R (kΩ)
<1.00
—
1.00–
6.67
6.67–
16.84
—
>16.84
RA=4.7 kΩ, RT=4.7 kΩ
U (V)
<2.41
—
2.41–
8.07
8.07–
10.74
—
>10.74
4K7
(Item 4)
R (kΩ)
<1.00
1.00–
3.42
3.42–
6.67
6.67–
16.84
—
>16.84
RA=4.7 kΩ, RT=2.35 kΩ,
RF=2.35 kΩ
U (V)
<2.41
2.41–
5.79
5.79–
8.07
8.07–
10.74
—
>10.74
4K7
(Item 7)
R (kΩ)
<1.00
16.84–
55.00
1.00–
6.67
6.67–
11.75
11.75–
16.84
>55.00
RA=4.7 kΩ, RT=4.7 kΩ,
RF=10 kΩ
U (V)
<2.41
10.74–
12.70
2.41–
8.07
8.07–
9.82
9.82–
10.74
>12.70
2K2
(Item 4)
R (kΩ)
<0.73
0.73–
1.47
1.47–
2.93
2.93–
5.87
—
>5.87
RA=2.2 kΩ, RT=1.1 kΩ,
RF=1.1 kΩ
U (V)
<1.90
1.90–
3.30
3.30–
5.30
5.30–
7.70
—
>7.70
6K8
(Item 4)
R (kΩ)
<2.27
2.27–
4.53
4.53–
9.07
9.07–
18.13
—
>18.13
RA=6.8 kΩ, RT=3.4 kΩ,
RF=3.4 kΩ
U (V)
<4.50
4.50–
6.80
6.80–
9.10
9.10–
11.00
—
>11.00
5K6
(Item 4)
R (kΩ)
<1.87
1.87–
3.73
3.73–
7.47
7.47–
14.93
—
>14.93
RA=5.6 kΩ, RT=2.8 kΩ,
RF=2.8 kΩ
U (V)
<3.90
3.90–
6.10
6.10–
8.50
8.50–
10.50
—
>10.50
