Chapter 2: Installation
Advisor Advanced ATSx500A(-IP) Installation and Programming Manual 29
Ethernet connection
Figure 22: Ethernet connection
(1) Ethernet RJ45
The Ethernet port is an IEEE 802.3u based connection supporting 10BASE-T or
100BASE-TX link speeds.
Use only FTP Cat 5e type cable for Ethernet connections.
IP
USB
MI
IP
(1)
