Chapter 2: Installation

32 Advisor Advanced ATSx500A(-IP) Installation and Programming Manual

Table 3: Zone and output numbering

Device

Zones

Outputs

Device

Zones

Outputs

Panel

1–8

2X ATS1810 relay

cards

—

17–24 [1]

Input expander

(ATS608)

9–16

N/A

Output expander

(ATS62x)

—

9–16 [2]

Expander 1

17–48

Keypad 1

—

1001–1008

Expander 2

49–80

Keypad 2

—

1009–1016

Expander 3

81–112

Keypad 3

—

1017–1024

Expander 4

113–144

Keypad 4

—

1025–1032

Expander 5

145–176

Keypad 5

—

1033–1040

Expander 6

177–208

Keypad 6

—

1041–1048

Expander 7

209–240

Keypad 7

—

1049–1056

Expander 8

241–272

Keypad 8

—

1057–1064

Expander 9

273–304

Keypad 9

—

1065–1072

Expander 10

305–336

Keypad 10

—

1073–1080

Expander 11

337–368

Keypad 11

—

1081–1088

Expander 12

369–400

Keypad 12

—

1089–1096

Expander 13

401–432

Keypad 13

—

1097–1104

Expander 14

433–464

Keypad 14

—

1105–1112

Expander 15

465–480 [3]

465–496

Keypad 15

—

1113–1120

Expander 16 [4]

497–528

Keypad 16

—

1121–1128

Expander 17

529–560

Keypad 17 [4]

—

1129–1136

Expander 18

561–592

Keypad 18

—

1137–1144

Expander 19

593–624

Keypad 19

—

1145–1152

Expander 20

625–656

Keypad 20

—

1153–1160

Expander 21

657–688

Keypad 21

—

1161–1168

Expander 22

689–720

Keypad 22

—

1169–1176

Expander 23

721–752

Keypad 23

—

1177–1184

Expander 24

753–784

Keypad 24

—

1185–1192

Expander 25

785–816

Keypad 25

—

1193–1200

Expander 26

817–848

Keypad 26

—

1201–1208

Expander 27

849–880

Keypad 27

—

1209–1216

Expander 28

881–912

Keypad 28

—

1217–1224

Expander 29

913–944

Keypad 29

—

1225–1232

Expander 30

945–976

Keypad 30

—

1233–1240

Keypad 31

—

1241–1248

Keypad 32

—

1249–1256

[1] Output 17 to 24 states are duplicated on ATS1810 relays and Expander 1 outputs.
