Chapter 2: Installation
36 Advisor Advanced ATSx500A(-IP) Installation and Programming Manual
Maximum voltage at power supply, auxiliary
power output and battery power output
14.5 V
Battery low condition
From 9.5 to 10.5 V
Battery test level [6]
11.2 V
Minimum voltage (battery recharging) at
power supply, auxiliary power output and
battery power output [7][8]
9.45 V
Maximum ripple voltage V, p-p [9]
100 mV typical, 300 mV max.
Overvoltage trigger value [10]
15.5 V min.
[1] The power supply voltage is monitored according EN 50131 Grade 3 and VdS-C regulations.
[2] Current available for auxiliary power and battery charge outputs.
[3] Maximum permanent current to power devices external to the control equipment in the
absence of alarm conditions. The sum of the auxiliary and COMM power output current
cannot exceed the maximum current specified in “Auxiliary current and battery capacityon
page 39.
[4] Battery output provides battery shortcut protection (according to VdS requirements).
[5] The housings applicable for particular batteries are specified in “Auxiliary current and battery
capacityon page 39.
[6] If during a manual or a programmed battery test the battery voltage drops below this
threshold, the battery test fails.
[7] Deep discharge protection mechanism monitors the battery voltage and disconnects the
battery if the voltage falls below indicated value, as required by EN 50131 Grade 3 and VdS-
C regulations.
[8] A specific fail message is generated when any output fails.
[9] Max ripple voltage only when empty battery is charging.
[10] Overvoltage protection mechanism monitors the power supply voltage and shuts down the
PSU if the voltage raises above indicated value, as required by EN 50131 Grade 3 and VdS-
C regulations.
General features
ATS1500A(-IP)
ATS3500A(-IP)
ATS4500A-IP
Code combinations
From 10,000 (4 digits) to 10 billion (10 digits)
End-of-line resistor
1 kΩ, 1.5 kΩ, 2 kΩ, 2.2 kΩ, 3.3 kΩ, 3.74 kΩ,
4.7 (default), 5.6 kΩ, 6.8 kΩ, 8.2 kΩ, 10 kΩ
Onboard zones
8 (expandable to 16 with 1X ATS608)
Maximum zone number
32
128
512
Onboard outputs
5 (expandable to 9 with 1X ATS624, or to 21 with
1X ATS626).
See “Standard onboard outputson page 37.
Maximum output number
128
Areas
4
8
64
Area groups
64
Maximum keypad / RAS number
8
16
32 [1]
Maximum expander / DGP number
7
15
30 [1]
[1] It is necessary to install ATS670 second RS485 LAN extension module to connect more
than 16 RASes and 15 DGPs.
