Chapter 5: Menu reference
Advisor Advanced ATSx500A(-IP) Installation and Programming Manual 199
5.1.n.6.1 Door zones
Use the menu to assign required zones to the selected door.
In case of standard door, there can be only one door zone indicating door
opening.
Note: It is not possible to assign a zone to a particular door function if this zone
is already used for other door function. Only unassigned zones are displayed.
5.1.n.6.1.1 Door zone
Select a zone with door contact for the selected door.
5.1.n.6.3 Alarm control
Set alarm control options for the selected door.
5.1.n.6.3.1 Door areas
1>Door areas
123456789012345>
Select door areas.
In case of an intelligent door, the areas specified here are used for:
• The reader LEDs if the option “5.1.n.3.5.5 LEDs option” described on page
206 is selected to show area status.
• “5.1.n.6.3.4.1 Deny access” when set (described on page 200).
• Option “5.1.n.6.4.3 Dis. when set” on page 209 is set to Yes for IN readers.
Although the areas are not used for area control, the door controller does need to
identify the status of these areas to know whether to send an arm or disarm
command to the control panel. This is only when using cards by themselves for
set/unset, for example, alarm control on 1st or 3rd badge. Remember that the
User group determines the areas allowed to be set or unset by a user, not the
areas listed here. See also “User groups” on page 62.
See “How to edit a list” on page 110 for details on the area selection.
Note: “2.2.1.n.3.3 View areas” on page 144 and “2.2.1.n.3.5 Control areas” on
page 145 are not available for keypads that are configured as door readers.
