Chapter 5: Menu reference
200 Advisor Advanced ATSx500A(-IP) Installation and Programming Manual
5.1.n.6.3.2 Door AGs
2>Door AGs
123456789012345>
Select door area groups in the same way as areas in “5.1.n.6.3.1 Door areas” on
page 199.
5.1.n.6.3.3 When unset
Define the door functionality when the assigned areas are unset.
5.1.n.6.3.3.1 Low Security
If set to yes, the door is operating in the low security mode when all door areas
are unset, which means the user authorization is changed from Card and PIN to
Card or PIN.
5.1.n.6.3.3.2 Unlock Door
If set to yes, the door is unlocked when all door areas are unset.
5.1.n.6.3.4 When set
Define the door functionality when the assigned areas are set.
5.1.n.6.3.4.1 Deny access
If set to Yes, the door access is denied unconditionally when any of door areas is
set.
5.1.n.6.3.4.2 Lock door
If set to Yes, the door is locked when all door areas are set.
