LED indication
DD66X
Dual
Red [1]
Yellow [1]
Alarm relay
To reset
Start up
Closed
Automatically after 45 s
Low voltage
Open
(Alarm)
Apply correct voltage
(Dual) motion
intruder alarm
Open
(Alarm)
Automatically after 3 s
Latched PIR
(Memory)
Switch to Night mode
DD66XAM
Dual / AM
Red [1]
Yellow LED
Alarm relay
AM relay
To reset
Start up
Closed
Closed
Automatically after
60 s
Low voltage
Open
(Alarm)
Open
(Alarm)
Apply correct voltage
(Dual) motion
intruder alarm
Open
(Alarm)
Automatically after 3 s
Latched PIR
(Memory)
Switch to Night mode
AM alarm
Open
(Alarm) [2]
Open
(Alarm)
See DIP switch 7
Technical fault
Open
(Alarm)
Pass walk test
Continuously on Normal blinking (1 Hz)
[1] Tri-colour LED.
[2] Depends on the setting of the DIP switch SW8.
Specifications
DD669
DD666-D
DD669AM
DD666AM-D
Detector
Dual
Dual + AM
Range diameter
(selectable)
20 ±0.5 m (65 ft. 7 in. ±1 ft. 7 in.)
or 12 ±0.5 m (39 ft. 4 in. ±1 ft. 7 in.)
Viewing angle
(selectable)
360 degrees or 180 degrees
Optical
2 x 9 curtains
Microwave
frequency
5.8 GHz
Max microwave
output at 1 m
0.003 μW/cm²
Memory
Yes
Input power
9 to 15 VDC (12 V nominal)
Peak-to-peak ripple
2 V (at 12 VDC)
Detector start-up
time
45 s
60 s
Normal current
consumption
12 mA
19 mA
Current consumption
in Alarm
10 mA
20 mA
Maximum current
consumption
15 mA
25 mA
Mounting height
2.5 to 5.0 m (8 ft. 2 in. to 16 ft. 5 in.)
DD669
DD666-D
DD669AM
DD666AM-D
Target speed range
0.3 to
3.0 m/s
(1 ft./s
to 9 ft.
10 in./s)
0.2 to
3.0 m/s
(8 in./s to
9 ft.
10 in./s)
0.2 to
3.0 m/s
(8 in./s to
9 ft. 10 in./s)
0.2 to 3.0 m/s
(8 in./s to 9 ft.
10 in./s)
Alarm (NC) / Tamper
relay characteristic
80 mA
30 VDC
Form A
80 mA
30 VDC
Form C
80 mA
30 VDC
Form A
80 mA
30 VDC
Form C
Pry off tamper
Optional
On board (Yes)
AM relay
characteristic
N/A
80 mA at 30 VDC max.
Alarm time
3 s
Operating
temperature
−10 to +55°C (14 to 130°F)
Dimensions ( x H)
 138 x 92 mm ( 5.43 in. x 3.62 in.)
Relative humidity
max. 95%
Weight
255 g (9 oz.)
IP/IK rating
IP30 IK04
Regulatory information
Manufacturer
UTC Fire & Security Americas Corporation, Inc.
3211 Progress Drive, Lincolnton, NC, 28092, USA
Authorized EU manufacturing representative:
UTC Fire & Security B.V.
Kelvinstraat 7, 6003 DH Weert, Netherlands
Certification
2002/96/EC (WEEE directive): Products marked with
this symbol cannot be disposed of as unsorted
municipal waste in the European Union. For proper
recycling, return this product to your local supplier
upon the purchase of equivalent new equipment, or
dispose of it at designated collection points. For more
information see: www.recyclethis.info.
Contact information
www.utcfireandsecurity.com or www.interlogix.com
For customer support, see www.utcfssecurityproducts.eu
DA: Installationsvejledning
Introduktion
DD66X/AM-serien består af µW + PIR/(µW + PIR-AM-
rumdetektorer. De indeholder den patenterede Range
Controlled Radar-teknologi (RCR).
Installationsvejledning
Detektoren kan monteres på et loft. Brug følgende
retningslinjer for at bestemme, hvor det er bedst at placere
detektoren:
• Monter detektoren, så den forventede bevægelse fra en
indbrudstyv går tværs igennem dens gardiner (figur 4
og 5).
• Monter detektoren på en stabil overflade ved en højde på
mellem 2,5 m og 5,0 m.
