SERVICE MENU
The service light will be “on” if the s ecurity system requires service. If the
service light is “on”, press the [ ] key followed by the [2] key to determine the
service condition. One or more zone lights will illuminate indicating what
service(s) is required. Call your service provider immediately for these
problems. Below is a listing of what each light means in a service condition.
LIGHT
PROBLEM
1
SYSTEM FAULT - Press the [1] key. The zone light(s) that is
illuminated corresponds to the system fault(s) below:
1 Over Current Fault
2 Siren Trouble
3 Box Tamper
4 Expander Power
5 Expander Low Battery
6 Expander Box Tamper
7 Expander Trouble
8 Ground Fault
Note: Faults 1 & 2 are global in nature and will affect all partitions of
a multi-partition system. Press the [#] key to return to the 1 of 8
service lights.
2
ZONE TAMPER - Press the [2] key and the zone light(s) will illuminate
showing the zone(s) that are tampered. Press the [#] key to return to
the 1 of 8 service lights.
3
ZONE LOW BATTERY - Press the [3] key. The zone light(s) will
illuminate showing which zone(s) has a low battery. This only applies
to wireless zones. Press the [#] key to return to the 1 of 8 service lights.
4
ZONE LOSS OF SUPERVISION - Press the [4] key and the zone light(s)
will illuminate showing which zone(s) has loss of supervision. This
only applies to wireless zones. Press [#] key to return to the 1 of 8
service lights.
5
ZONE TROUBLE - Press the [5] key and the zone light(s) will illuminate
showing which zone(s) has a trouble condition. Press the [#] key to
return to the 1 of 8 service lights.
6 
TELEPHONE FAULT - Press the [6] key. The zone light(s) that is
illuminated corresponds to the system fault(s) below:
6
Line Trouble / Line Cut - This light will illuminate when there is
telephone line trouble or the telephone line has been cut. The
service light will remain lit until the telephone trouble clears
and a user code is entered.
7
Auxiliary Comm Device Fail - Radio backup has failed.
7 
FAILURE TO COMMUNICATE - This light will illuminate when there is a
failure to communicate between your system and the central station.
8 
LOSS OF SYSTEM TIME - This light will illuminate when there has
been a loss of power and your system clock needs to be reset.
Instructions are on page 13.
EXIT
Press the [#] key to exit the Service Light mode.
 Note: This fault is global in nature and will affect all partitions of a multi-
partition system.
