20 Simon XT User Manual
Table 9: Siren sounds
Function
Fire
Intrusion
Emergency
Interior and panel
siren*
Temporal 3
Steady
Fast on/off
Interior and panel
siren*
Temporal 3
Steady
Fast on/off
Interior and panel siren
Temporal 3
Steady
Fast on/off
Exterior siren
Temporal 3
Steady
* This feature is not verified for use by UL.
Note: Temporal 3 refers to a continuous pattern of three siren pulses, then off for 1.5 seconds,
three siren pulses, then off for 1.5 seconds.
Panel indicator lights
Use Table 10 below to understand the panel indicator lights.
Table 10: Indicator light
Button
When button light is on
When button flashes
Doors+Windows
Doors and windows armed
Doors and window armed and
no entry delay on
Motions
Motions armed
Motion sensors armed and
latchkey on
Disarm
System disarmed
System subdisarmed
Status
System trouble, open sensor,
or bypassed sensor
System in alarm
OK
There are no open sensors
Chime (solid bell)
Door will cause chime
Special chime (outlined bell)
Motion will cause chime
Light schedules (clock)
Time-activated lights feature
enabled
Sensor lights (light bulb)
Sensor-activated lights feature
enabled
Latchkey on (key)
Latchkey feature enabled
Trouble beeps
Your security system is able to automatically test itself for:
• Power failures
• Low batteries
• Nonworking sensors

Interlogix Simon XT Specifications

Power

power requirements	6V nominal
standby current	30mA (10mA in PowerSave Mode)
peak current	1.7 A

Operating Environment

operating temperature	32 to 120°F (0 to 49°C)
storage temperature	-30 to 140°F (-34 to 60°C)
max. relative humidity	90% non-condensing

Dimensions

height	4 1/16 in.
width	1 7/8 in.
