6 ZSim v5.XX User‘s Guide
[ParamName] ParamNo ParamValue Default Comment
Control
Instruction Prefix
21 ~ Any ASCII char.
Command
Delimiter
22 , Any ASCII char.
Units inch/mm 23 1/0 0 0=inch, 1=mm
Optimize Batch 24 -1/0 -1 ON/OFF
Y-offset in percent 25 0 Skid comp.+/-0.1-
5.0
Character Set 26 0 0 Single byte char. set
Media Type 50 0/1/2 0 0=GAPS, 1=STRIP,
2=MARK
Paper Type 51 auto TT or DT (setup)
XSTART 52 0 (setup)
Factory default 53 1
Debug off/on 54 0/1 0 0=OFF, 1=ON
Line Analyser 55 1 OFF 1=ON
Baudrate 60 115200 9600,…,115200
Char.length 61 8 8,7
Parity 62 NO NO,EVEN,..
Stop Bits 63 1 1,2
Flowcontrol,
RTS/CTS
64 ENABLE ENABLE/DISABLE
65 DISABLE ENABLE/DISABLE
Xon/xoff data to
host
66 DISABLE ENABLE/DISABLE
Xon/xoff data
from host
67 DISABLE ENABLE/DISABLE
Sample 1 Change Start Adjust to -130:
^ZX Start Adjust,7,-130^FS or ^ZX7,-130^FS
Sample 2 Change Print Mode to peel-off:
^ZX Print Mode,6,P^FS or ^ZX6,P^FS
