26 Numbers in [brackets] are for 50 Hz international systems. Pub. No. 18-HE122D1-1-EN
Installer’s Guide
Dimensions
(all dimensions in inches)
21” DEPTH CABINET
ADD DOOR DEPTH FOR TOTAL
OUTLINE DRAWING FOR AIR HANDLERS
AIR HANDLER MODEL NUMBERS
ifD Air Cleaner A
B (multiple
piece cabinet)
B (one piece
cabinet)
EFD175CLAH000E 17.5 14.9 15
EFD215CLAH000E 21.5 18.9 19
EFD235CLAH000E 23.5 20.9 21
EFD260CLAH000E 26.0 23.4 23.5
7-7/16
Side View
AIRFLOW
2.8”
21
1/8
1/8
Front
of
Cabinet
A
B
18.88
