KEY PART NO. DESCRIPTION QTY.
1 40809 Flue Collar 1
2 40789 Top, Cast Iron 1
3 88257 3/8" Top Rope Gasket 6.5 ft
4 88256 Kao Wool 1
5 27737 Top Heat Shield 1
6 40788 Back, Cast Iron 1
7 88257 3/8" Back Rope Gasket 5 ft
8 40786 Side, Cast Iron 2
9 892651 Tube Assembly 1
10 88257 3/8" Bottom Rope Gasket 5.5 ft
11 40782 Bottom, Cast Iron 1
12 27735 Inner Heat Shield 1
13 27736 Outer Heat Shield 1
14 40790 Leg 4
15 89975 Handle Bracket 1
16 88257 3/8" Front Rope Gasket 5ft
17 40783 Front, Cast Iron 1
18 40787 Hearth, Cast Iron 1
19 892652 Air Intake Box 1
20 88174 Gasket - Flat, Glass (3/16T x 3/8W) 11 in
21 88257 3/8" Door Rope Gasket 2.5 ft
22 40785 Door, Cast Iron 1
23 89975 Handle Extension 1
24 891135 Handle, Spring (Lg-Nickel) 1
PARTS LIST
CAUTION:
NEVER ALTER THE DAMPER SLIDE OR THE ADJUSTMENT RANGE TO INCREASE FIRING RING FOR ANY
REASON. DOING SO COULD RESULT IN HEATER DAMAGE AND WILL VOID YOUR WARRANTY.
