Technical Features
Enclosure ABS (V-0, 5VB). 2,1 mm thickness
PC (V-2). 1 mm thickness
Dimensions 81 x 78 x 28 mm
Weight 76 g
Colour White
Power supply 5VDC 0,25 A NEC Class 2 or Limited Power Source (LPS) and
SELV rated Power supply
Radio Parameters Wi-Fi 802.11 (b/g/n)
RF Frequency range: 2412 to 2497 MHz
Output power (average): 8 dBm
(Modulated signal at antenna port; 11Mb/Sec.)
LED indicators 1 x Device status
Button 1 x Push button
Temperature sensor 1 x Internal temperature sensor
Infrared communication 1 x Infrared receiver
2 x Infrared emitter
Binary Input 1 x Minijack connection (3.5mm stereo jack)
Operating Temperature From 0ºC to 40ºC
Operating humidity <93% HR, no condensation
Stock humidity <93% HR, no condensation
RoHS conformity Compliant with RoHS directive (2011/65/EU)
