PARTS REFERENCE (continued)
Before assembling your product, please take a few minutes to check the contents
and become familiar with all the parts.
NOTE:
Drawings for illustration purpose only. Actual product may vary. Not to scale.
REF.
NO.
DESCRIPTION
QTY.
SPARE PART
NO.
Individually Pool Set
9
PLUNGER VALVE (HOSE O-RING &
STEP WASHER INCLUDED)
0 2 10747
10 HOSE O-RING 2 4 10262
11 STEP WASHER 0 2 10745
12 STRAINER NUT 1 2 10256
13 FLAT STRAINER RUBBER WASHER 1 2 10255
14 THREADED STRAINER CONNECTOR 0 1 10744
15 ADJUSTABLE POOL INLET JET NOZZLE 1 1 12369
16 AIR JET VALVE 1 1 12363
17 INLET THREADED AIR CONNECTOR 1 1 12371
18 AIR JET VALVE CAP 1 1 12373
19 STRAINER GRID 0 1 12198
9
10
11 12 13 14
19
OUTLET
If the pump was purchased as part of a pool set, below fi tting parts are included.
Contact our Authorized Service Centers to order these parts if needed.
When ordering parts, be sure to quote the model number and part numbers.
9
10
11
12
13
17
15
16
INLET
18
To Next Page
