OPERATING INSTRUCTIONS (continued)
Operating the sand filter pump under ʺTIMERʺ mode or manually:
To operate the sand filter pump in ʺFILTERʺ mode under ʺTIMERʺ
control:
1. Activate the unit:
Press
button. Flashing code ʺ00ʺ appears on the LED display,
indicating that the unit is ready to be programmed.
2. Set operating hours for the filter pump:
With code ʺ00ʺ flashing, press
button
to set the desired operating hours. See the
ʺOperating Time Tableʺ for the required
operating hours related to each pool size.
Pressing
will increase the time from 01
to 12 hours maximum. If you have selected
too many hours keep pressing to repeat
the cycle. The built-in timer will now activate the Sand filter pump, at the same time each day,
for the number of hours you have set.
3.
Lock keypad controls:
With the desired hour value showing, press
to lock the keypad controls which prevents
unauthorized changing of the operating cycle.
NOTE:
If you forget to lock the keypad controls, the system will automatically lock it and start
working 10 seconds later.
The sand filter pump is now filtering the water and will stop after the operating hours are
completed.
4.
Readjust operating time if necessary:
The operating hours can be re-adjusted if necessary. Press
button and the current
programmed time will flash. Repeat steps 2 to 3.
5. Stand-by/power saving mode:
•
When the cycle ends, the LED display
shows ʺ93ʺ. The system is now in Stand-By
mode. After 5 minutes the system goes into
Power Saving mode and the LED display
shows ʺ.ʺ. The system will automatically turn
itself back on in 24 hours.
•
While the system is in Power Saving mode,
press any button and the system will briefly
display the programmed time and then ʺ93ʺ.
(1 to 12 hours max per cycle)
