120A
SAVE THESE INSTRUCTIONS
(120IO) SEQUOIA SPIRIT™ WOOD-GRAIN FRAME POOL ENGLISH 7.5” X 10.3” PANTONE 295U 05/26/2016
English
Page 6
REF. NO. DESCRIPTION
POOL SIZE & QUANTITIES
15'8" x 49"
(478 cm x124 cm)
18'8" x 53"
(569 cm x 135 cm)
1
PIN (WITH 2 EXTRA)
32
38
2
SEAL (WITH 2 EXTRA)
32
38
3
T - JOINT
15
18
4
SPRING PIN
15
18
5
VERTICAL LEG (SPRING PIN INCLUDED)
15
18
6
LEG CAP
15
18
7
HORIZONTAL BEAM
15
18
8
POOL LINER (DRAIN VALVE CAP INCLUDED)
1
1
9
DRAIN CONNECTOR
1
1
10
DRAIN VALVE CAP
1
1
11
GROUND CLOTH
1
1
12
WATERPROOF CAP (WITH 4 EXTRA)
34
40
13
BOLT (WITH 4 EXTRA)
34
40
14
TOP CLAMP COVER
15
18
15
TOP BOARD
15
18
16
TOP CLAMP
15
18
17
SUPPORT POST
15
18
18
PLUNGER VALVE CONNECTOR
2
2
19
STRAINER VALVE CAP
2
2
20
SIDE BOARD A
116
141
21
SIDE BOARD B
0
17
22
SIDE BOARD COMBINATION WITH TWO HOLES
1
1
23
SIDE BOARD COMBINATION WITH ONE HOLE
1
1
24
BOTTOM RAIL
15
18
25
BOTTOM CAP
15
18
26
BOLT WRENCH
2
2
REF. NO. DESCRIPTION
15'8" x 49"
(478 cm x124 cm)
18'8" x 53"
(569 cm x 135 cm)
SPARE PART NO.
1
PIN (WITH 2 EXTRA)
10312
10312
2
SEAL (WITH 2 EXTRA)
10648
10648
3
T - JOINT
10861
10862
4
SPRING PIN
10313
10313
5
VERTICAL LEG (SPRING PIN INCLUDED)
10864
10865
6
LEG CAP
10309
10309
7
HORIZONTAL BEAM
10414
10414
8
POOL LINER (DRAIN VALVE CAP INCLUDED)
11490
11110
9
DRAIN CONNECTOR
10201
10201
10
DRAIN VALVE CAP
11044
11044
11
GROUND CLOTH
18927
11290
12
WATERPROOF CAP (WITH 4 EXTRA)
12172
12172
13
BOLT (WITH 4 EXTRA)
12173
12173
14
TOP CLAMP COVER
12174
12174
15
TOP BOARD
12199
12199
16
TOP CLAMP
12200
12200
17
SUPPORT POST
12201
12202
18
PLUNGER VALVE CONNECTOR
11040
11040
19
STRAINER VALVE CAP
11240
11240
20
SIDE BOARD A
12203
12203
21
SIDE BOARD B
12204
12204
22
SIDE BOARD COMBINATION WITH TWO HOLES
12205
12205
23
SIDE BOARD COMBINATION WITH ONE HOLE
12206
12207
24
BOTTOM RAIL
12208
12208
25
BOTTOM CAP
12218
12218
26
BOLT WRENCH
11053
11053
To Next Page
