(307IO) HEAT PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 12/15/2016
English
307
IO
SAVE THESE INSTRUCTIONS
English
Page 10
SET UP INSTRUCTIONS (continued)
Typical above ground pool arrangement
Typical in-ground pool arrangement
Pool
Filter
Pump
Chemical
Treatment
Heat Pump
Power
Cable Inlet
Condensation
Draining Pipe
Water to Pool
Water Pump
Filter
Check Valve
Chemical
Treatment
Water
from Pool
NOTE:
To allow water to ow into the heat pump, make sure the valve in the middle of the bypass
kit is closed and the other two valves on the sides are open.
To Next Page
