Intex Krystal Clear QX2100 User Manual

(332IO) 48”, 52” LADDER WITH REMOVABLE STEPS ENGLISH 4.875” X 7.25” PANTONE 295U 04/26/2022
332
A
S AVE THESE INSTRUCTIONS
Page 10
5. U-SHAPED TOP RAIL INSTALLATION
(refer to figures 5.1 through 5.2):
IMPORTANT:
One side at a time. Do not attach the other side of the ladder until the
U-shaped top rail is installed. Make sure all nuts and bolts are securely tightened. Do not
fully tighten fasterners until last assembly operation.
6. SIDE B LEGS INSTALLATION
(refer to figure 6):
LADDER SETUP (continued)
1
B
A
4 (M6*35)
5.1
1
6
2
B
A
C
C
5 (M6*40)
4 (M6*35)
5.2
1
2

Intex Krystal Clear QX2100 Specifications

General

Type	Sand Filter Pump
Voltage	110-120V
Shape	Cylindrical
Flow Rate	5.7 m³/h
Features	6-function control valve
Hose Diameter	38 mm
Suitable for Pool Volume	up to 12, 800 gallons
Included Accessories	Hoses
