Intex Krystal Clear QX2100 User Manual

(97IO) DELUXE MAINTENANCE KIT ENGLISH SIZE: 4.875” X 7.25” PANTONE 295U 05/26/2022
97
A
SAVE THESE INSTRUCTIONS
Page 11
POOL VACUUM SETUP INSTRUCTIONS
1
2
3
Set up the surface skimmer by following the floating surface skimmer manual.
Turn off filter pump.
Remove the basket (9), cover rim (7) and the floating cover (6) from the
skimmer.
6
7
9
Place the debris bag (4) in the vacuum body (5). Press and hold the
clip on the vacuum body and close the vacuum cover (3) by turning
clockwise.
PRESS
4
Place the vacuum assembly into the skimmer, turn clockwise to connect.
3
4
5
2
1
3
4
5
3
3
5
10
10
16
16
1
2

Intex Krystal Clear QX2100 Specifications

General

Type	Sand Filter Pump
Voltage	110-120V
Shape	Cylindrical
Flow Rate	5.7 m³/h
Features	6-function control valve
Hose Diameter	38 mm
Suitable for Pool Volume	up to 12, 800 gallons
Included Accessories	Hoses
