SAVE THESE INSTRUCTIONS
Page 10
(110) MODEL 634 FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 07/07/2009
English
SSEETTUUPP IINNSSTTRRUUCCTTIIOONNSS
FILTER PUMP STATIONARY MOUNTING OPTION
Some countries, especially in the European community, require the filter-pump to
be secured to the ground or to a base in a permanent upright position. Check your
local authorities to determine if there is a regulation in your area regarding
above-the-ground swimming pool filter-pumps. If yes, then the filter-pump can be
mounted to a platform using the two holes located in the base. See drawing below.
The filter-pump can be mounted on a cement base or onto a wooden platform to
prevent accidental falling over. Total assembly must exceed 18kg.
165 mm
1. The mounting holes are 6.4 mm in diameter and spaced 165 mm apart.
2. Use two bolts and lock nuts with a maximum of 6.4 mm in diameter.
