PAGE 29
OWNER’S MANUAL
Intimidator Tow Capacity Chart
Model Max. Towed Load Max. Towed Max. Rear Hitch Max. Front Hitch Maximum Towing Maximum Towing
Weight on Load Weight Tongue Weight Tongue Weight Speed on level Speed on
level ground* on 15 degree grade* ground* 15 degree grade*
Intimidator EV 1,500 lbs. 500 lbs. 200 lbs. 300 lbs. 10 mph (16 kph) 5 mph (8 kph)
Intimidator EV XD4 1,500 lbs. 500 lbs. 200 lbs. 300 lbs. 10 mph (16 kph) 5 mph (8 kph)
*In low range
