PAGE 8
WARNING
Keep hands, body, and other people away from
pinch points when lowering bed.
Do not hold the cage/frame while closing bed.
Tire Pressure Chart
TIRE PRESSURE AND SIZE CHART
ROHVA and ISO certification sticker – Located on the ROPS
Vehicle Size Load Air Top Speed Rating Max
Position Rating (lb) Pressure (psi) (mph) @ Max Load Payload
Front 26x9R14 750 18 10 Loaded
Rear
26x11R14 1275 22 10
Front 26x9R14 680 12 25 Unloaded
Rear
26x11R14 1000 12 25
