86
Dimensions Comet
Comet
Alpine
Comet
HD
Overall width (armrest
adjustment range)
• 630 ... 725 mm
Total height
• 1255 mm • 1290 mm
Seat width
• 510 mm • 660 mm
Seat depth
• 485 mm • 535 mm
Seat height
• 440 / 465 / 490 / 515 mm
Backrest angle
• 95° ... 145° • 95° ... 120°
Armrest height
• 200 ... 245 mm
Weight Comet
Comet
Alpine
Comet
HD
Kerb weight
• 3-wheel: 133 kg
• 4-wheel: 136 kg
• 4-wheel: 143 kg • 4-wheel: 148 kg
Component weights
Chassis
• 3-wheel: approx. 60 kg
• 4-wheel: approx. 63 kg
Batteries
• approx. 26 kg per battery
Seat unit
• approx. 21 kg
Payload
Comet / Comet
Alpine
Comet
HD
Max. payload
• 160 kg • 220 kg
Axle loads Comet
Comet
Alpine
Comet
HD
Max. front axle load
• 3-wheel: 86 kg
• 4-wheel: 87 kg
• 4-wheel: 90 kg • 4-wheel: 110 kg
Max. rear axle load
• 3-wheel: 206 kg
• 4-wheel: 209 kg
• 4-wheel: 212 kg • 4-wheel: 258 kg
