Invacare Comet ULTRA - Replacing Steering Column

Service
4.
LoosenandremovescrewAthatattachesswingarmto
chassisonleftandrightsideofthemobilitydevice.
5.
LoosenandremovelowerboltBonrearshockabsorber
onleftandrightsideofmobilitydevice.
BecarefulnottoloosemetalbushingAinswing
armB.
6.Removeandreplaceswingarm.
7.
Installpartsinreverseorder.
Whenreinstalling,tightenscrewAto15Nm.
4.8.4Replacingsteeringcolumn
CAUTION!
Riskofaccident
Accidentalrollingcanleadtoaccidents.
–Securemobilitydeviceagainstrollingaway.
Whendisassembling,notethepositionofsmallparts
suchasscrewsandwashers.Putsmallpartsdownso
thattheycanbereassembledintherightsequence.
•10mmwrench
•13mmwrench
•17mmwrench
•19mmwrench
•32mmwrench
•Phillipsscrewdriver
•Supportingwoodenblock
1.Removeseat.
2.Removeshroud.
3.Disconnectbatterycable.
4.
Placeasupportingwoodenblockunderthefrontpartof
theframesothatthefrontwheelisnolongertouching
theoor.
