TYPICAL PRODUCT PARAMETERS
Leo Scooter 2 Part No. 1163141
WARNING
Procedures other than those described in this manual must be performed by a qualified
technician.
DO NOT use this product or any available optional equipment without first completely reading
and understanding these instructions and any additional instructional material such as owner’s
manuals, service manuals or instruction sheets supplied with this product or optional equipment.
If you are unable to understand the warnings, cautions or instructions, contact a healthcare
professional, dealer or technical personnel before attempting to use this equipment - otherwise,
injury or damage may occur.
ACCESSORIES WARNING
Invacare products are specifically designed and manufactured for use in conjunction with
Invacare accessories. Accessories designed by other manufacturers have not been tested by
Invacare and are not recommended for use with Invacare products.
TYPICAL PRODUCT PARAMETERS
NOTE:Alldimensionsare±.50inchesunlessotherwiseindicated.
*NOTE:Weightlimitationistotalweight(userweightplusanyadditionalitemsthattheusermayrequire[backpack,etc.]).Example:
Ifweightlimitationofthescooteris350lbsandadditionalitemsequal25lbs,subtract25lbsfrom350
lbsthismeansthemaximum
weightlimitationoftheuseris325lbs.
LEO 4-WHEEL SCOOTER
OVERALL DIMENSIONS
OVERALL LENGTH:
DRIVE UNIT WIDTH:
OVERALL WIDTH:
OVERALL HEIGHT:
48 inches
23.2 inches
23 to 29 inches (armrest adjustment range)
39 inches
SEAT DIMENSIONS
WIDTH:
DEPTH:
SEAT HEIGHT:
19 inches
16 inches
16.5 to 19.5 inches
ARM DIMENSIONS
ARMREST HEIGHT: 8 inches
SPEED 5 mph
MAXIMUM INCLINE CAPABILITY 8° Grade
TURNING RADIUS: 52 inches
WEIGHT OF PRODUCT: 184 lbs
MAXIMUM WEIGHT LIMITATION 350 lbs
NOTE:Updatedversionsofthismanualareavailableonwww.invacare.com.
