SECTION 8—FRONT CASTERS
Part No. 1114811 51 Lightweight, Standard and Heavy Duty Wheelchairs
FIGURE 8.2 Replacing Front Casters
Replacing/Repairing Front Caster Tire/Tube
WARNING
Replacement of front caster tire or tube MUST be performed by a qualified technician.
CAUTION
As with any vehicle, the wheels and tires should be checked periodically for cracks
and wear, and should be replaced when necessary.
Locknut
Washer (if applicable)
Front Caster
8-Inch Fork
Hex Screw
Washer (if applicable)
To Next Page
