Invacare Lynx Series Manual

44
SPECIFICATIONS
S
P
E
C
I
F
I
C
A
T
I
O
N
S
SPECIFICATIONS
K NOTE: with Optional Deluxe Seat.
*NOTE: Total weight of scooter includes Contour Seat
Only. Add an additional 9-lbs for Deluxe Seat.
L NOTE: Flat free inserts are standard on all wheels.
LYNX (3-Wheel Models) PANTHER (4-Wheel Models)
SX-3P SX-3 LX-3 LX-3
Plus
LX-4 MX- 4
Overall Length: 43.5-inches (104 cm) 43.5-inches (104 cm) 47-inches (119 cm) 47-inches (119 cm) 47.5-inches (125 cm) 54-inches (137 cm)
Overall Width: 23-inches (58 cm) 23-inches (58 cm) 25-inches (64 cm) 25-inches (64 cm) 25-inches (64 cm) 26-inches (66 cm)
Ground
Clearance: 3.5-inches (8.89 cm) 3.5-inches (8.89 cm) 3-inches (7.62 cm) 3-inches (7.62 cm) 3.25-inches (8.26 cm) 6-inches (15.24 cm)
Seat Height
From Floor Pan:
Contour Seat: 14-1/2-inches (37 cm) 14-1/2-inches (37 cm) 14-1/2-inches (37 cm) 14-1/2-inches (37 cm) N/A N/A
15-1/2-inches (39 cm) 15-1/2-inches (39 cm) 15-1/2-inches (39 cm) 15-1/2-inches (39 cm)
16-1/2-inches (42 cm) 16-1/2-inches (42 cm) 16-1/2-inches (42 cm) 16-1/2-inches (42 cm)
17-1/2-inches (44 cm) 17-1/2-inches (44 cm)
Deluxe Seat: N/A N/A 15-inches (38 cm) 15-inches (38 cm) 16-1/2-inches (42 cm) 17-inches (43 cm)
16-inches (41 cm) 16-inches (41 cm) 17-1/2-inches ( 44 cm) 18-inches (46 cm)
17-inches (43 cm) 17-inches (43 cm) 18-1/2-inches (47 cm) 19-inches (48 cm)
18-inches (46 cm) 18-inches (46 cm) 19-1/2-inches (49 cm)
Armpad to
Floor:
Fixed: 21-1/2-inches (55 cm) 21-1/2-inches (55 cm) 21-1/2-inches (55 cm) 21-1/2-inches (55 cm) 23-inches (58 cm) N/A
K22-1/2-inches (57 cm) K22-1/2-inches (57 cm)
Adjustable: N/A N/A 21-inches (53 cm) 21-inches (53 cm) 22-1/2-inches (57 cm) 21-inches (53 cm)
22-inches (56 cm) 22-inches (56 cm) 23-1/2-inches (60 cm) 22-inches (56 cm)
23-inches (58 cm) 23-inches (58 cm) 24-1/2-inches (62 cm) 23-inches (58 cm)
24-inches (61 cm) 24-inches (61 cm) 25-1/2-inches (65 cm) 24-inches (61 cm)
Weights:
Front Frame
Section: 31-lbs (14 kg) 39 -lbs (17 Kg) 47 -lbs (21 kg) 47 -lbs (21 kg) 48 -lbs (22 kg) 75 -lbs (34 kg)
Rear Frame
Section: 35 -lbs (16 kg) 35 -lbs (16 kg) 38 -lbs (17 kg) 38 -lbs (17 kg) 39 -lbs (18 kg) 58 -lbs (26 kg)
Contour Seat
w/arms 22 -lbs (10 kg) 22 -lbs (10 kg) 22 -lbs (10 kg) 22 -lbs (10 kg) N/A N/A
Deluxe Seat
w/Arms N/A N/A 31-lbs (14 kg) 31-lbs (14 kg) 35 -lbs (16 kg) 43 -lbs (19 kg)
Rear Shroud 2-lbs (1 kg) 2-lbs (1 kg) 3 -lbs ( 1 kg) 3 -lbs ( 1 kg) 2 -lbs (1 kg) 4 -lbs (2 kg)
Batteries:(each) 14 -lbs (6 kg) 14 -lbs (6 kg) 23 -lbs (10 kg) 23 -lbs (10 kg) 23-lbs (10 kg) 31-lbs (14 kg)
Total Weight
of Scooter
w/o Batteries: 90-lbs (41 kg) 98-lbs (44 kg) *110-lbs (50 kg) *110-lbs (50 kg) 124-lbs (56 kg) 180-lbs (82 kg)
w/ Batteries: 118-lbs (53 kg) 126-lbs (57 kg) *156-lbs (70 kg) *156-lbs (70 kg) 170-lbs (77 kg) 242-lbs (110 kg)
LWheel Size
Front: 2 x 8-inches 2 x 8-inches 2-1/2 x 9-inches 2-1/2 x 9-inches 3 x 10-inches 4 x 13-inches
(5.08 x 20.32 cm) (5.08 x 20.32) cm (6.35 x 22.86 cm) (6.35 x 22.86 cm) (7.62 x 25.40 cm) (10.16 x 33.02 cm)
Rear: 2-1/2 x 9-inches 2-1/2 x 9-inches 3 x 10-inches 3 x 10-inches 3 x 10-inches 4 x 13-inches
(6.35x22.86 cm) (6.35x22.86 cm) (7.62 x 25.40 cm) (7.62 x 25.40 cm) (7.62 x 25.40 cm) (10.16 x 33.02 cm)
Max. Weight
Limitation: 250 lbs (114 kg ) 250lbs (114 kg ) 300lbs (136 kg ) 300lbs (136 kg ) 300 lbs (136 kg ) 400 lbs (181 kg)
Maximum
Speed: 4-1/2 M.P.H. 4-1/2 M.P.H. 5 M.P.H. 5 M.P.H. 5-1/2 M.P.H. 5¼ M.P.H. 7¼ M.P.H.
7-1/4 K.P.H. 7-1/4 K.P.H 8 K.P.H 8 K.P.H 9 K.P.H 8½ K.P.H 11¾ K.P.H
Max. Incline
and Stability: 8
o
incline 8
o
incline 8
o
incline 8
o
incline 8
o
incline 8
o
incline
LOW HIGH
