Orion
5.
Loosenaxlebolts(1)simultaneouslyonbothsides.
6.
Pullfrontaxleslowlyout.
7.Replacefrontaxle.
8.Replacepartsinreverseorder.
9.Testfunction(trialrun).
4.8.5Replacingsteeringcolumn
CAUTION!
Riskofaccident
Accidentalrollingcanleadtoaccidents.
Securemobilitydeviceagainstrollingaway.
Whendisassembling,notethepositionofsmallparts
suchasscrewsandwashers.Putsmallpartsdownso
thattheycanbereassembledintherightsequence.
10mmwrench
17mmwrench
19mmwrench
32mmwrench
Phillipsscrewdriver
Supportingwoodenblock
1.Removeseat.
2.Removeshroud.
3.Disconnectbatterycable.
4.
Placeasupportingwoodenblockunderthefrontpartof
theframesothatfrontwheelisnolongertouchingoor.
Replacingsteeringcolumn
1.
RemovedriveleverscrewsC.
2.RemovedriveleverB.
3.LoosenandremovescrewsAonoperatingconsole.
4.Removeoperatingconsole.
5.
RemovescrewsAonrearsteeringcolumnshroud.
6.Removesteeringcolumnshroud.
7.Loosenscrewsonfrontbasketholder.
8.Removebasketholder.
9.Removespacerbushes.
10.Disconnectcablefromwiringharness.
22
1608032-A

Questions and Answers:

Invacare orion metro Specifications

General IconGeneral
Turning Radius260 cm (102 inches)
Ground Clearance2.5 inches (6.35 cm)
Seat Width17.5 inches (44.5 cm)
Maximum Speed4 mph (6.4 km/h)
Weight Capacity136 kg (300 lbs)
Top Speed4 mph (6.4 km/h)
Drive SystemRear-wheel drive
Brake SystemElectromagnetic
