General
Call supplier
This product complies with Directive
93/42/EEC concerning medical devices.
The launch date of this product is stated in the
CE declaration of conformity.
For more details about CE marks, refer to Typical Product
Parameters.
Symbols on Product
Unit running
Unit not running
O
2
Indicators
Symbol O
2
Purity Indicator Lights (LED)
O
2
SYSTEM OKAY
O
2
over 85%
GREEN Indicator Light
O
2
between 73% to
85%
YELLOW Indicator Light
A. YELLOW Solid
B. YELLOW Flashing
Sensor
Failure
Call a qualified technician
SYSTEM FAILURE
O
2
Below 73%
RED Indicator Light
Continuous Audible
Alarm Sieve — GARD™
Compressor Shutdown
1195656-A 5

Invacare Perfecto2 HomeFill IRC5PO2AW Specifications

General

Flow Rate	0.5 to 5 LPM
Outlet Pressure	5.5 PSI
Warranty	3 years
Oxygen Concentration	87% to 95.6%
Electrical Requirements	60 Hz
Dimensions	23 in H x 13 in W x 12 in D
