Invacare Pronto M50 - User Manual

Other manuals for Invacare Pronto M50

Service Manual132 pages

Parts Catalog100 pages

Brochure & Specs2 pages

Questions and Answers

J
Jessica HuynhAug 18, 2025
What to do if my Invacare Pronto M50 will not drive?
- J
  janetcampbellAug 18, 2025
  If your Invacare Wheelchair won't drive, several factors could be at play. First, ensure the motor release levers are engaged. Second, the batteries may need charging; make sure the setting on the charger is correct. Third, check if the charger is plugged in and unplug it before operating the wheelchair. Finally, the circuit breaker might have tripped; reset it. If it trips again, it may indicate an internal repair is needed, so contact your dealer or Invacare.
C
Chad BeardAug 20, 2025
Why does the battery indicator on my Invacare Wheelchair flash low after recharging?
- M
  Melissa MartinezAug 20, 2025
  If your Invacare Wheelchair battery indicator flashes low immediately after recharging, it could be due to weak batteries or a charger malfunction. Replacing the batteries or the charger might solve the issue. You may need to contact your dealer or Invacare.
A
Amy NavarroAug 23, 2025
How to increase driving distance of Invacare Pronto M50 Wheelchair?
- Z
  znelsonAug 23, 2025
  If you are experiencing limited driving distance with your Invacare Wheelchair, the batteries may not be charged long enough or may be too weak to hold a charge. To resolve this, charge the batteries overnight, ensuring at least 8 hours of charge time between uses, and verify the correct setting on the charger. If the problem persists, consider replacing the batteries.
M
Michael LeeAug 26, 2025
Why does my Invacare Pronto M50 Wheelchair charger show low charge after charging?
- G
  Gregory JonesAug 26, 2025
  If the charger indicator shows a low charge level immediately after charging your Invacare Wheelchair, it could be due to weak batteries, an electrical malfunction, or a charger malfunction. You may need to replace the batteries or the charger. You may need to contact your dealer or Invacare.
Y
Yolanda WilliamsonAug 27, 2025
What to do if Invacare Wheelchair batteries are not charging?
- L
  Lisa HesterAug 28, 2025
  If your Invacare Wheelchair batteries are not charging, the charger may not be working, or the battery connections may be loose. There might not be any current at the wall outlet, or there could be a bad connection on the charger, charger cable, plug, or internal wiring. Have the charger replaced, check and secure all connections, and switch to another wall outlet. If problems persist, the charger may need replacing or internal repairs. You may need to contact your dealer or Invacare.
B
Becky MedinaAug 30, 2025
Why does my Invacare Pronto M50 slow down when Seat Function 1 is lit?
- W
  William DavidAug 30, 2025
  If your Invacare Wheelchair slows or stops while driving and the Seat Function 1 indicator is lit, it is because the elevating seat is elevated. Return the seat to its lowest position.
R
Ryan JonesSep 2, 2025
Why is the joystick on my Invacare Pronto M50 not responding correctly?
- S
  Stephen LopezSep 2, 2025
  If the joystick on your Invacare Wheelchair is erratic or not responding as desired, it could be due to an electrical malfunction or the controller being programmed improperly. You may need to contact your dealer for service or reprogram the controller.
J
josephsullivanSep 4, 2025
Why do Invacare Pronto M50 Wheelchair batteries draw excessive current when charging?
- W
  williamescobarSep 4, 2025
  If your Invacare Wheelchair batteries draw excessive current when charging, it is likely due to battery failure. Have the batteries checked for a shorted cell and replace them if necessary.
T
Tony SmithSep 6, 2025
Why does only one wheel turn on my Invacare Wheelchair?
- C
  Colin AlvarezSep 6, 2025
  If only one drive wheel turns on your Invacare Wheelchair, it could be due to an electrical malfunction or one of the motor locks being disengaged. Contact your dealer for service or engage the motor lock.
J
Jason HartmanSep 9, 2025
What causes an Invacare Wheelchair to not respond to commands?
- N
  Nancy SullivanSep 9, 2025
  If your Invacare Wheelchair does not respond to commands, it may be due to a poor battery terminal connection. Have the terminals cleaned.

Summary

Section 1: General Guidelines

Controller Settings, Repair, or Service

Instructions for initial setup and adjustments of the electronic control unit by qualified technicians.

Operation Information

Charging Batteries

Safe procedures for recharging batteries, including extension cord usage and grounding instructions.

Section 3: Safety and Handling of Wheelchairs

Stability and Balance

Ensuring proper balance and stability by maintaining proper posture and avoiding extreme leaning.

Lifting and Stairways

Procedures and warnings for safely moving the wheelchair, especially when using stairs.

Transferring To and From Other Seats

Instructions for safe transfers, emphasizing power off and motor release lever engagement.

Percentage of Weight Distribution

Reaching, Leaning, and Bending

Section 4: Safety Inspection and Troubleshooting

Safety Inspection Checklists

Procedures for initial, weekly, monthly, and periodic inspections of wheelchair components.

Troubleshooting Guide

Common symptoms, probable causes, and solutions for wheelchair operational issues.

Section 5: Wheelchair Operation

Powering the Wheelchair On and Off

Instructions for turning the wheelchair's power on and off using the joystick controls.

Driving the Wheelchair with the Joystick

How to use the joystick for smooth control of speed and direction.

Adjusting Wheelchair Speed

Methods for adjusting the maximum speed using the speed control knob or buttons.

Horn and Seat Elevation

Joystick Controls and Indicators

Overview of joystick types, buttons, indicators, and their functions for operation and diagnostics.

Section 6: Arms

Adjusting the Arms

Section 7: Seat

Removing and Installing the Seat Assembly

Section 8: Footboard Assembly

Removing and Installing the Footboard Assembly

Section 9: Front Riggings

Section 10: Top Shroud and Wheels

Engaging and Disengaging Motor Release Lever

How to engage or disengage motor release levers for freewheeling or powered operation.

Section 11: Batteries

Battery Handling and Safety Warnings

Essential safety precautions for handling and replacing wheelchair batteries.

Battery Removal and Installation

Step-by-step guide for removing and installing batteries from the battery tray.

Battery Cable Management

Instructions for connecting and disconnecting battery cables safely.

Battery Charging Procedures

Guidelines for charging batteries using on-board and independent chargers.

Section 12: Electronics

Removing and Installing the Joystick

Disconnecting and Connecting the Joystick

Steps for safely disconnecting and reconnecting the joystick connector.

Section 13: Accessories

Invacare Pronto M50 Specifications

Performance

maximum speed	3 mph
incline capability	9º
weight capacity	300 lb.

Power

motor power	350-watt
on-board charger	3-amp

Weight and Dimensions

length with footboard folded	34"
length with footboard down	38" - 40"
width excluding joystick	24"
height	35"-37"
seat width	18"
seat depth	16"-18"
weight with batteries	205 lb.
weight without batteries	155 lb.
front caster size	6" x 1.3"
drive wheel size	10.5" x 3.5"
rear caster size	6" x 1.3"
turning radius front with footboard down	19.5"
turning radius rear	19.5"
ground clearance	3.8"
