Page 8
WARNING for Using R32/R290 Refrigerant
European Disposal Guidelines
This appliance contains refrigerant and other potentially hazardous materials. When disposing of
this appliance, the law requires special collection and treatment. Do not dispose of this product as
household waste or unsorted municipal waste.
When disposing of this appliance, you have the following options:
• Dispose of the appliance at designated municipal electronic waste collection facility.
• When buying a new appliance, the retailer will take back the old appliance free of charge.
• The manufacturer will take back the old appliance free of charge.
• Sell the appliance to certied scrap metal dealers.
Special notice
Disposing of this appliance in the forest or other natural surroundings endangers your health and is
bad for the environment. Hazardous substances may leak into the ground water and enter the food
chain.
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
This marking shown on the product or its literature, indicates that waste electrical and
eletrical equipment should not be mixed with general household waste.
2
2
2
2
2
2
When ammable refrigerant are employed, appliance shall be stored in a well -ventilated area
where the room size corresponds to the room area as speciec for operation.
For R32 frigerant models:
Appliance shall be installed, operated and stored in a room with a oor area larger than 4m .
Appliance shall not be installed in an unvertilated space, if that space is smaller than 4m .
For R290 refrigerant models, the minimum room size needed:
<=9000Btu/h units: 13m
>9000Btu/h and <=12000Btu/h units: 17m
>12000Btu/h and <=18000Btu/h units: 26m
>18000Btu/h and <=24000Btu/h units: 35m
Reusable mechanical connectors and ared joints are not allowed indoors.
(EN Standard Requirements).
Mechanical connectors used indoors shall have a rate of not more than 3g/year at 25%
of the maximum allowable pressure. When mechanical connectors are reused indoors,
sealing parts shall be renewed. When ared joints are reused indoors, the are part
shall be re-fabricated. (UL Standard Requirements)
When mechanical connectors are reused indoors, sealing parts shall be renewed. When
ared joints are reused indoors, the are part shall be re-fabricated.
(IEC Standard Requirements)
Mechanical connectors used indoors shall comply with ISO 14903.
Page 8
Illustrations in this manual are for explanatory purposes. The actual shape of your indoor unit
may be slightly different. The actual shape shall prevail.
NOTE: Different models have different front panel and display window. Not all the indicators
describing below are available for the air conditioner you purchased. Please check the indoor display
window of the unit you purchased.
Power Cable
(Some Units)
Remote Control
Remote Control
Holder (Some Units)
Louver
Front Panel
Air Filter
(pull up)
Display window
(A)
(B)
(C)
ECO intelligent eye
(some units)
Display Code
Meanings
Unit Specications and Features
Indoor unit display
“ ” for 3 seconds when:
“ ” when defrosting(for cooling & heating units)
“ ” when Active Clean feature is turned on(For Inverter split type )
when the Self clean feature is turned on (For xed-speed type)
“ ” when ECO feature is activated(some units)
“ ” when wireless control feature is activated(some units)
“ ” “ ”Displays temperature, operation feature and Error codes:
“ ” when 8°C(46°F) heating mode is turned on(some units)
Humidity
Boost
“ ” for 3 seconds when:
• TIMER ON is set (
if the unit is OFF, remains on when TIMER ON is set )
• FRESH, UV-C lamp, SWING, TURBO , ECO, BREEZE AWAY, ECO
INTELLIGENT EYE or SILENCE feature is turned on
• TIMER OFF is set
•
FRESH, UV-C lamp, SWING, TURBO , ECO, BREEZE AWAY, ECO
INTELLIGENT EYE or SILENCE feature is turned off
“ ”
To Next Page
