INVERTER POOL PUMP
INSTALLATION & OPERATION MANUAL
Model: B
+
InverSilence15 / B
+
InverSilence22
This manual contains important informationthat will
help you in operating and maintaining this product.
Please read the manual carefully beforeinstallation &
operation and retain it for future reference.
Thank you for purchasing our inverter pool pumps.

Questions and Answers

  • C
    Christine KellyAug 7, 2025
    What to do if INVERSilence Tech B+InverSilence15 does not start?
    • S
      Shannon VillaAug 7, 2025
      If your INVERSilence Tech Swimming Pool Pump isn't starting, begin by checking the power supply for any faults, disconnections, or defective wiring. Also, inspect the fuses and thermal overload; replace any blown fuses or reset the thermal overload. Ensure the motor shaft rotates freely without obstruction. If necessary, unplug the power and manually rotate the motor's rear shaft a few times using a screwdriver.
  • M
    Megan SchultzAug 15, 2025
    Why is my INVERSilence Tech B+InverSilence15 Swimming Pool Pump being noisy?
    • S
      Steven MartinezAug 15, 2025
      If your INVERSilence Tech Swimming Pool Pump is making excessive noise, there could be several reasons. First, check for air leaks in the suction piping and seal them. Cavitation due to a restricted or undersized suction line, or leaks at any joint, can also cause noise, so inspect and correct any suction line restrictions. Ensure the pool water level is adequate. Check the pump installation and correct any improper installation that may cause vibration. If the noise persists, there may be damage to the motor bearing or impeller, in which case you should contact the supplier for repair.
  • O
    Oscar BrownAug 22, 2025
    What to do if INVERSilence Tech Swimming Pool Pump won't prime?
    • P
      penakimAug 22, 2025
      If your INVERSilence Tech Swimming Pool Pump won't prime, start by ensuring the pump and strainer housing are filled with water and the cover o-ring is clean. Check for loose connections on the suction side and tighten them. Also, inspect the strainer and skimmer baskets for debris and clean them if necessary. Clear any clogs in the suction side. Verify that the distance between the pump inlet and the liquid level is not higher than 2.5m; if it is, lower the pump installation height.
  • D
    Diana ThomasAug 29, 2025
    How to fix low water flow in INVERSilence Tech Swimming Pool Pump?
    • B
      Brian CherryAug 30, 2025
      To address low water flow in your INVERSilence Tech Swimming Pool Pump, first ensure that the pump is properly primed. Check for air entering the suction piping and identify and seal any leaks. Clean the pump basket if it's full of debris. Also, verify that the water level in the pool is adequate and increase it if necessary.
