involight PAINTBAR HEX12PP - Page 7

SP 9
Microphone sensivity
SEnS
SE 1
-
SE 9
SENS:1 = min. sensitivity,
SENS:9 = max. sensitivity
Colormixing.
This mode offers the
possibility to separately
control each of the 6
colors of the LEDs (R,
G, B, W, A and UV) in
intensity and thus to
produce an unlimited
number of different
colors
CoLo
R000
-
R255
Red,
Intensity 0% - 100%
G000
-
G255
Green,
Intensity 0% - 100%
B000
-
B255
Blue,
Intensity 0% - 100%
U000
-
U255
White,
Intensity 0% - 100%
A000
-
A255
Amber,
Intensity 0% - 100%
U000
-
U255
UV,
Intensity 0% - 100%
Master Dimmer
dIMM
dI 1
-
dI 9
Master dimmer for static colors and Internal
programs.
Silent-Mode
SILE
on
If the silent mode is activated "ON", the light
beams of the unit switch off (BLACKOUT) if no
further music signals (bass impulses) are
received.
oFF
If the silent mode is deactivated "OFF" - the
current program of the device will continue
slowly if no further music signals (bass
impulses) are received.
Slave Mode
SLAV
Master / Slave operation. Define the device as
"Slave".
Control via IR remote
control
InFr
on
IR remote control activated.
oFF
IR remote control de-activated.
