involight PAINTBAR HEX12PP - Assignment of the DMX Channels in the Overview

3.3 Assignment of the DMX channels in the overview:
NOTE: Basic knowledge of the DMX512 control standard is required so that the device can be
correctly operated and Programed with a DMX controller.
5 Channel Mode:
DMX Mode
Channel
Value
Description
Comments
5 CH
1
000 - 255
Master Dimmer 0 - 100%
Influences all
functions of CH3 and
CH4
2
000 - 009
No Function
Influences all
functions of CH3 and
CH4
010 - 255
Stroboscope: slow → fast
3
000 - 009
No Function
010 - 019
RED
COLOR PRESETS
020 - 029
GREEN
030 - 039
BLUE
040 - 049
WHITE
050 - 059
AMBER
060 - 069
UV
070 - 079
YELLOW
080 - 089
MAGENTA
090 - 099
CYAN
100 - 109
DARK ORANGE
110 - 119
GREEN YELLOW
120 - 129
SALMON
130 - 139
TURQUISE
140 - 149
LIGHT GREEN
150 - 159
ORANGE
160 - 169
LAVENDER
170 - 179
LIGHT BLUE
180 - 189
DARK BLUE
190 - 199
PINK
200 - 255
No Function
4
000 - 009
No Function
010 - 019
Auto Program 1
Auto
020 - 029
Auto Program 2
030 - 039
Auto Program 3
040 - 049
Auto Program 4
050 - 059
No Function
060 - 069
Sound Program 1
Sound
070 - 079
Sound Program 2
080 - 089
Sound Program 3
