INVT GD20-055G-4

Goodrive20 inverters Function Parameters
70
Function
code
Name Detailed instruction of parameters
Default
value
Modify
power loss 0:Save when power off
1:Clear when power off
LED tens: Action selection when MODBUS set frequency
off
0:Save when power off
1:Clear when power off
LED hundreds:The action selection when other frequency
set frequency off
0:Save when power off
1:Clear when power off
P08.48
High bit of
original power
consumption
This parameter is used to set the original value of the power
consumption.
The original value of the power consumption
=P08.48*1000+ P08.49
Setting range of P08.48: 0~59999 kWh (k)
Setting range of P08.49:0.0~999.9 kWh
0 kWh
○
P08.49
Low bit of
original power
consumption
0.0 kWh
○
P08.50
Magnetic flux
braking
coefficient
This function code is used to enable magnetic flux.
0: Invalid.
100~150: the bigger the coefficient, the bigger the braking
strength.
This inverter can slow down the motor by increasing the
magnetic flux. The energy generated by the motor during
braking can be transformed into heat energy by increasing
the magnetic flux.
The inverter monitors the state of the motor continuously
even during the magnetic flux period. So the magnetic flux
can be used in the motor stop, as well as to change the
rotation speed of the motor. Its other advantages are:
Brake immediately after the stop command. It does not
need to wait the magnetic flux weaken.
The cooling is better. The current of the stator other than the
rotor increases during magnetic flux braking, while the
cooling of the stator is more effective than the rotor.
0
○
P08.51
Input power
factor of the
inverter
This function code is used to adjust the displayed current of
the AC input side.
Setting range:0.00~1.00
0.56
○
P09 Group PID control
P09.00
PID
reference
source
When the frequency command selection (P00.06, P00. 07)
is 7 or the voltage setting channel selection (P04.27) is 6,
0
○
