8-Port USB DVI KVM Switch
AUTO SCAN K/M RESET
1
2 3 4 5 6 7 8
6
1
5 4 23
2
1
34
5
Overview
Front view
1. Port 1~8 switch Button
2. Power LED
3. Reset Button
4. USB Sharing Port
5. Firmware Upgrade Recovery Switch
Back view
1. Powe Jack
2. CPU 1 - 8 Port
3. Console Port
4. Grounding
5. Firmware upgrade Port
