1 Introduction
The compact Victorem 2KSDI-Mini camera series is designed for a broad range of applications, from
specialty video production to aircraft or vehicle recording and security or surveillance. The high-
quality Sony CMOS sensors give the 2KSDI-Mini cameras outstanding image quality and high
dynamic range. Table 1 shows the camera models covered in this manual.
Model Sensor Resolution Optical
Format
Shutter
2KSDI-Mini
2KSDI-Mini D
Sony Pregius IMX265 2048 x 1080 8.9mm (Type 1/1.8) Global
2KMSDI-Mini
2KMSDI-Mini D
Sony Pregius IMX252 2048 x 1080 8.9mm (Type 1/1.8) Global
2KM5SDI-Mini Sony Pregius IMX250 2464x2056 2/3” (11.1mm) Global
2KSDI-Mini RS
2KSDI-Mini RS D
Sony Exmor-R
IMX183
4096 x 2160 2/3” (11.1mm) Rolling
Table 1. Covered Victorem 2KSDI-Mini models
1.1 Output Formats
The supported output formats for the 2KSDI-Mini cameras are shown in Table 2. Outputs from the
2KSDI-Mini RS and 2KSDI-Mini RS D are scaled down from the full sensor resolution. 2K outputs
are scaled from 4096x2160 (4K) and HD outputs are scaled from 3840x2160 (UHD). The 2KSDI-Mini
RS and 2KSDI-Mini RS D do not support 1280x720 output.
Interface Resolution Output Format Frame Rate (Hz)
Single 3G-SDI
SMPTE 424M
2048 x 1080 (2K) 4:2:2 Y'Cb'Cr'/ RAW 47.95, 48, 50, 59.94, 60
2048 x 1080 4:4:4 R'G'B' 23.98, 24, 25, 29.97, 30
1920 x 1080 (HD) 4:2:2 Y'Cb'Cr' / RAW 50, 59.94, 60
1920 x 1080 4:4:4 R'G'B' 23.98, 24, 25, 29.97, 30
Single HD-SDI
SMPTE 292M
2048 x 1080 4:2:2 Y'Cb'Cr' / RAW 23.98, 24, 25, 29.97, 30
1920 x 1080 4:2:2 Y'Cb'Cr' / RAW 23.98, 24, 25, 29.97, 30
1920 x 1080 Interlaced 4:2:2 Y'Cb'Cr'/ RAW 50, 59.94, 60
(field rates 25, 29.97, 30)
1280 x 720
1
4:2:2 Y'Cb'Cr' / RAW 50, 59.94, 60
1
Not supported on 2KSDI-Mini RS
Table 2. Supported output formats
