35 VICTOREM 2KSDI-Mini User's Manual
7.1 Command Summary
Table 15 summarizes all available commands. The presence and size of a command's parameters are
shown with the letter 'Y' (see Format column). Each letter 'Y' represents a hexadecimal digit from 0 to
f.
Command Format Description
VARIANT
Variant Version var Returns variant version of firmware.
VIDEO FORMAT
Resolution res Y Output resolution:
0 – 720p (not available in 2KSDI-Mini RS)
1 – 1080i
2 – 1080p (default)
3 – 2K
Image Sampling sam Y Image sampling:
0 – 4:2:2 YCbCr (default)
1 – RAW (default for 2KMSDI-Mini)
2 – 4:4:4 RGB
Frame Rate fps Y Output frame rate:
0 – 23.98Hz
1 – 24Hz
2 – 25Hz
3 – 29.97Hz
4 – 30Hz (default)
5 – 47.95Hz
6 – 48Hz
7 – 50Hz
8 – 59.94Hz
9 – 60Hz
TRI-LEVEL SYNC
Sync Enable syn Y 0 – off
1 – on
Sync Shift sys YYY Shift output relative to sync input.
Range 0x0001 – 0x1fff (-7.76ms to 7.76ms)
Camera subtracts 1000h from parameter for signed 12-bit
value and each count represents 1.896μS
Sync shift only applies when sync first enabled, will return
NAK if sync enabled
