36 VICTOREM 2KSDI-Mini User's Manual
Command Format Description
Sync Detect syd Returns 4-bit value (single hex digit)
Bit 0 – line locked
• Current output clock trained to TLS line time ('1').
Bit 1 – frame locked
• Output frame locked to TLS input, with +/- 8 line
times (0
H
analog point) ('1').
Bit 2 – match detected
• TLS input matches current camera output rate ('1').
Bit 3 – input detected
• TLS input signal detected ('1').
Note, if the current sync state is drifting (“x001”, sync
unplugged or frequency changed) and a command is sent
that restarts the sensor framing (rst, lnk, res, sam, fps, lod
and flp in RS model) the sync control block will reset back
to a not locked state (“xx00”).
EXPOSURE
Exposure Time exp YYY Exposure time in lines (H)
Range 0x001 – 0x454
GAIN AND OFFSET
Sensor Sensitivity iso Y Sensitivity in ½ F stop (3dB) increments
Range 0 – 16
Changing ISO will be reflected in agn setting, and vice versa
Gain agn YYY Range 0x000 – 0x1E0
Gain in 0.1dB steps
2KSDI-Mini
• Analog gain 0x000 – 0x0F0, up to 24dB
• Digital gain 0x0F1 – 0x1E0, 24.1 to 48dB
2KSDI-Mini RS
• Analog gain 0x000 – 0x10A, up to 26.6dB
• Digital gain 0x10B – 0x1E0, 26.7dB to 48dB
Sensor Black Level blk YYY Range 0x000 – 0xFFF
Default 0x000
Not recommended to change
MISCELLANEOUS
Bad Pixel Replacement bpx Y 0 – off
1 – on
Test Pattern pat Y 0 – off
1 – color bars (static)
2 – color bars (dynamic)
IO Industries Inc. www.ioindustries.com Revision 3.0
