37 VICTOREM 2KSDI-Mini User's Manual
Command Format Description
RS485 Baud Rate sbd Y 0 – 9600
1 – 19200
2 – 38400
3 – 57600
4 – 115200 (default, remote)
5 – 230400
6 – 460800
Image Flip flp Y 0 – off
1 – vertical flip
2 – horizontal flip
3 – both direction flip
Note RS model only support vertical flip
Flat Field Correction
Flat Field Calculate ffc Run the flat field correction calibration.
Flat Field Save ffs Y Range 1-4
Save the current flat field correction to one of four flat field
correction tables in non-volatile memory.
Flat Field Load ffl Y Range 0-4
Load desired flat field correction from non-volatile memory.
0 – clear current flat field correction
EF LENS CONTROL
RS232 Baud Rate lbd Y 0 – 9600
1 – 19200 (default)
2 – 38400
3 – 57600
4 – 115200
Learn Focus Enable fen Y 0 – Do not automatically learn focus (savable command)
1 – Automatically learn focus
Aperture ape YY Range depends on lens
Smaller the number the more open aperture
Focus Step Size fst YY Range 0x04 – 0xC8
Default 0x14
AUTO ZONE (EXPOSURE AND WHITE BALANCE)
Zone X Position apx Y Range 0-4
Default 2
Zone size changes with output resolution:
720P – 426 x 240
1080I/P – 640 x 360
2K – 682 x 360
Start column = apx x (zone width/2)
Y Position apy Y Range 0-4
Default 2
Start row = (4 - apy) x (zone height/2)
IO Industries Inc. www.ioindustries.com Revision 3.0
